Technical specs - 407 JCB
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 5.06 t
- Standard tyres
- 365/80 R18
- Bucket width
- 1.9 m
- Bucket capacity
- 0.8 m³
- Bucket capacity min.
- 0.8 m³
- Steering mode
- KL
- Transport length
- 5.13 m
- Transport width
- 1.73 m
- Transport height
- 2.5 m
- Travel speed
- 20 km/h
- Max. discharge height
- 2.49 m
- Turning radius outside
- 4.16 m
- Lifting force
- 41.9 kN
- Model series
- 400
- Engine manuf.
- Kohler
- Engine type
- KDI2054TCR
- Engine power
- 48 kW
- Displacement
- 2.482 l
- Revolutions at max torque
- 1500 rpm
- Max. torque
- 300 Nm
- No. of cylinders
- 4
- Emission level
- V
More technical details, like: bucket capacity max., dimension lxwxh, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin, std. shovel and teeth
Special equipment
- Diesel particulate filter
-
Yes
- Swing loader
-
No
- telescopic
-
No
- Aircondition
-
No
- Quick hitch hydr.
-
Yes
- Quick hitch mech.
-
No
