407 JCB 407 Specifications & Technical Data (2014—2019)

The JCB 407 is a wheel loader manufactured by JCB from 2014 to 2019. It has a weight of 5.06 tons and a transport length of 5.13 m…

The JCB 407 is a wheel loader manufactured by JCB from 2014 to 2019. It has a weight of 5.06 tons and a transport length of 5.13 meters. The bucket capacity is 0.8 cubic meters with a bucket width of 1.9 meters. The maximum discharge height is 2.49 meters and it has a travel speed of 20 km/h. The transport width is 1.73 meters and the transport height is 2.5 meters. It has a lifting force of 41.9 kN and a turning radius outside of 4.16 meters. The special equipment included is a quick hitch hydr.

Visit JCB live at

407

Years of manufacture: 2014—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
Events
News

Technical specs - 407 JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.06 t

Standard tyres: 365/80 R18

Bucket width: 1.9 m

Bucket capacity: 0.8 m³

Bucket capacity min.: 0.8 m³

Steering mode: KL

Transport length: 5.13 m

Transport width: 1.73 m

Transport height: 2.5 m

Travel speed: 20 km/h

Max. discharge height: 2.49 m

Turning radius outside: 4.16 m

Lifting force: 41.9 kN

Engine manuf.: Kohler

Engine type: KDI2054TCR

Engine power: 48 kW

Displacement: 2.482 l

Revolutions at max torque: 1500 rpm

Max. torque: 300 Nm

No. of cylinders: 4

Emission level: III B

More technical details, like: bucket capacity max., model series, dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

JCB 407 FAQ

When was the JCB 407 manufactured?

The JCB 407 was manufactured from 2014 to 2019.

How much does the JCB 407 wheel loader weigh?

The JCB 407 wheel loader weighs 5.06 tons.

What are the transport dimensions of the JCB 407 wheel loader?

The JCB 407 wheel loader has a transport length of 5.13 meters, a transport width of 1.73 meters, and a transport height of 2.5 meters.

What is the travel speed of the JCB 407 wheel loader?

The JCB 407 wheel loader has a travel speed of 20 km/h.

What is the standard tyre size of the JCB 407 wheel loader?

The JCB 407 wheel loader is equipped with standard tyres sized 365/80 R18.

What are the maneuverability specifications of the JCB 407 wheel loader?

The JCB 407 wheel loader has an articulated-frame steering system and an outside turning radius of 4.16 meters.

What is the lifting force of the JCB 407 wheel loader?

The JCB 407 wheel loader has a lifting force of 41.9 kN.

What is the maximum discharge height of the JCB 407 wheel loader?

The JCB 407 wheel loader has a maximum discharge height of 2.49 meters.

What are the specifications of the primary work tool bucket on the JCB 407 wheel loader?

The JCB 407 wheel loader has a bucket with a capacity of 0.8 cubic meters, a minimum bucket capacity of 0.8 cubic meters, and a bucket width of 1.9 meters.

How much is a JCB 407 Wheel loader (2014u20132019) worth?

The residual value of the JCB 407 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

JCB 407 overview

JCB 407 features overview

Productivity and cost benefits

By providing information like idle time monitoring and machine fuel consumption, JCB LiveLink helps reduce your fuel usage, saving money and improving productivity. Machine location information can help improve efficiency and perhaps even reduce insurance costs.

Maintenance benefits

Manage machine maintenance easily – accurate hours monitoring and service alerts improve maintenance planning, while real-time location data helps you manage your fleet. Critical machine alerts and maintenance history records are also available.

Security benefits

LiveLink’s real-time geofencing alerts tell you when machines move out of predetermined zones, and real-time curfew alerts inform you of unauthorised usage. Further benefits include real-time location information.

Engine / Powertrain / Drivetrain

Productive Performance

The JCB 406, 407 and 409 are highly productive wheel loaders with optimal power-to-weight ratio, making them perfect tool carriers. Both larger machines are Tier 4 Final/Stage IV-compliant using just a diesel oxidation catalyst (DOC). They’re also more frugal than outgoing Tier 3 models.

Versatility by the bucketload

Equip your wheel loader with our new towing option and you’ll get a hitch with rear electrics and hydraulics, allowing you to trailer loads of up to 3.5 tonnes or carry rear attachments like salt spreaders. By splitting power between the transmission and the hydraulics, our inching pedal allows precise, efficient, stepless load handling. Our wheel loaders are even more versatile when you use both front and rear attachments; you could, for example, combine a snow plough and rear grit spreader.

Hydraulic system

General Machine Features

Parallel lift geometry, JCB Hydraulic Quickhitch, articulated steering, front and rear fenders, one piece opening bonnet, recovery hitch, lifting lugs, temperature controlled engine cooling fan.

Operator's cab

Hydraulics

Single lever manual control, gear pump with priority steer, emergency steer back up. ROPS/FOPS safety structure, fully adjustable seat, interior light, adjustable tilt steering column, safety glass, front and rear screen wash/wipe, 3 speed heater fan with replaceable filters, sun visor.

Bucket and Ground Engaging Tools

Built to last.

We understand how tough materials handling can be, so our machines are developed to be highly durable. A case in point is our heavy-duty centre joint, which oscillates through ± 10°. These machines benefit from a strong chassis and the best possible weight distribution; this allows for the best possible absorption of external forces.
