JCB 406 Specifications & Technical Data (2020-2024)

Name: JCB 406 Wheel Loaders
Brand: JCB

The JCB 406 is a wheel loader manufactured by JCB since 2020. It has a weight of 4.87 tons and a transport length of 5.13 meters. …

The JCB 406 is a wheel loader manufactured by JCB since 2020. It has a weight of 4.87 tons and a transport length of 5.13 meters. The bucket capacity is 0.8 cubic meters with a bucket width of 1.9 meters. The maximum discharge height is 2.49 meters and it has a travel speed of 20 km/h. The transport width is 1.73 meters and the transport height is 2.5 meters. It has a lifting force of 41.9 kN and a turning radius outside of 4.16 meters. The bucket capacity ranges from a minimum of 0.8 cubic meters to a maximum of 1 cubic meter. It is equipped with a diesel particulate filter and a quick hitch hydr.

Technical specs - 406 JCB

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.87 t

Standard tyres: 365/80 R18

Bucket width: 1.9 m

Bucket capacity: 0.8 m³

Bucket capacity min.: 0.8 m³

Bucket capacity max.: 1 m³

Steering mode: KL

Transport length: 5.13 m

Transport width: 1.73 m

Transport height: 2.5 m

Travel speed: 20 km/h

Max. discharge height: 2.49 m

Turning radius outside: 4.16 m

Lifting force: 41.9 kN

Engine manuf.: Kohler

Engine type: KDI1903TCR

Engine power: 36.4 kW

Dimension lxwxh: 704.3x452.5x667.5 mm

Displacement: 1.903 l

Revolutions at max torque: 1500 rpm

Max. torque: 170 Nm

No. of cylinders: 3

Emission level: V

More technical details, like: model series, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No
