LX 190 Hitachi LX 190 Specifications & Technical Data (2003—2026)

The Hitachi LX 190 is a wheel loader manufactured since 2003. It has a weight of 19.77 tons and a transport length of 8.51 meters.…

The Hitachi LX 190 is a wheel loader manufactured since 2003. It has a weight of 19.77 tons and a transport length of 8.51 meters. The bucket capacity is 3.5 cubic meters with a width of 3.05 meters. The maximum discharge height is 4.18 meters. It has a travel speed of 34.5 km/h and a transport width of 2.93 meters. The transport height is 3.41 meters. The lifting force is 166 kN and the turning radius outside is 5.82 meters. It is equipped with air conditioning.

Wheel Loaders Hitachi LX 190

Visit Hitachi live at

Technical specs - LX 190 Hitachi

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
19.77 t
Standard tyres
23.5-25-16PR (L3)
Bucket width
3.05 m
Bucket capacity
3.5 m³
Steering mode
KL
Transport length
8.51 m
Transport width
2.93 m
Transport height
3.41 m
Travel speed
34.5 km/h
Max. discharge height
4.18 m
Turning radius outside
5.82 m
Lifting force
166 kN
Engine manuf.
Mitsubishi
Engine type
6D24TL
Engine power
165 kW
Displacement
11.945 l
Revolutions at max torque
2100 rpm

More technical details, like: bucket capacity min., bucket capacity max., model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Hitachi LX 190 FAQ

When was the Hitachi LX 190 manufactured?

The Hitachi LX 190 was first produced in 2003.

How much does the Hitachi LX 190 wheel loader weigh?

The Hitachi LX 190 wheel loader weighs 19.77 tons.

What are the transport dimensions of the Hitachi LX 190 wheel loader?

The Hitachi LX 190 has a transport length of 8.51 meters, a transport width of 2.93 meters, and a transport height of 3.41 meters.

What is the travel speed of the Hitachi LX 190 wheel loader?

The Hitachi LX 190 has a travel speed of 34.5 km/h.

What are the standard tyre specifications of the Hitachi LX 190 wheel loader?

The Hitachi LX 190 wheel loader has standard tyres sized 23.5-25-16PR (L3).

What are the maneuverability specifications of the Hitachi LX 190 wheel loader?

The Hitachi LX 190 wheel loader has an outside turning radius of 5.82 meters and uses articulated-frame steering for maneuverability.

What is the power rating of the Hitachi LX 190 wheel loader?

The source data does not provide power rating information for the Hitachi LX 190 wheel loader.

What is the maximum discharge height of the Hitachi LX 190 wheel loader?

The Hitachi LX 190 wheel loader has a maximum discharge height of 4.18 meters.

What are the specifications of the bucket on the Hitachi LX 190 wheel loader?

The bucket on the Hitachi LX 190 has a capacity of 3.5 cubic meters and a width of 3.05 meters.

How much is a Hitachi LX 190 Wheel loader (2003u20132025) worth?

The residual value of the Hitachi LX 190 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Hitachi LX 190 overview

Hitachi LX 190 features overview

Maintenance Access

The large side cover opens to provide easy access. In addition, items requiring daily maintenance have been centrally located on the left side for faster servicing.


Engine / Powertrain / Drivetrain

Independent front and rear service brakes

Separate brake lines for the front and rear wheels means that one will be available for braking in the unlikely event that the other fails.


3-mode switch

Automatic transmission provides selection among three power modes: (L) gives priority to traveling; (M) is an intermediate range; (H) is for loading operations.


Hydraulic system

Front arm can be lowered with engine stopped

An accumulator in the hydraulic system for the front arm allows it to be lowered even if the engine has been stopped.


Operator's cab

ROPS/FOPS cab

This rigid cab is ready to help protect the operator from falling objects or during a rollover. The rear-hinged door makes entry and exit easy.


External air induction air conditioning

This powerful air conditioning can be switched between re-circulating air inside the cab or drawing it in from outside.
