KL 158 Gehlmax KL 158 Specifications & Technical Data (2002—2007)

The Gehlmax KL 158 is a wheel loader manufactured by Gehlmax from 2002 to 2007. It has a weight of 1.36 tons and a transport lengt…

The Gehlmax KL 158 is a wheel loader manufactured by Gehlmax from 2002 to 2007. It has a weight of 1.36 tons and a transport length of 3.5 meters. The bucket capacity is 0.23 cubic meters, with a maximum discharge height of 2.72 meters. The travel speed of this machine is 15 km/h. It has a transport width of 0.85 meters and a transport height of 2.25 meters. The bucket capacity minimum is also 0.23 cubic meters. Additionally, it is equipped with a quick hitch mechanism.

KL 158

Years of manufacture: 2002—2007

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - KL 158 Gehlmax

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.36 t

Standard tyres: 7.00x12AS6PR

Bucket capacity: 0.23 m³

Bucket capacity min.: 0.23 m³

Steering mode: KL

Transport length: 3.5 m

Transport width: 0.85 m

Transport height: 2.25 m

Travel speed: 15 km/h

Max. discharge height: 2.72 m

Model series: KL

More technical details, like: bucket width, bucket capacity max., turning radius outside, lifting force, engine manuf., engine type, engine power, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders...

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Gehlmax KL 158 FAQ

When was the Gehlmax KL 158 manufactured?

The Gehlmax KL 158 was manufactured from 2002 to 2007.

How much does the Gehlmax KL 158 wheel loader weigh?

The Gehlmax KL 158 wheel loader weighs 1.36 tons.

What are the transport dimensions of the Gehlmax KL 158 wheel loader?

The Gehlmax KL 158 has a transport length of 3.5 meters, a transport width of 0.85 meters, and a transport height of 2.25 meters.

What is the travel speed of the Gehlmax KL 158 wheel loader?

The Gehlmax KL 158 has a travel speed of 15 km/h.

What are the undercarriage tyre specifications of the Gehlmax KL 158 wheel loader?

The Gehlmax KL 158 wheel loader is equipped with standard tyres sized 7.00x12AS6PR.

What is the steering mode of the Gehlmax KL 158?

The Gehlmax KL 158 has articulated-frame steering.

What is the maximum discharge height of the Gehlmax KL 158?

The Gehlmax KL 158 has a maximum discharge height of 2.72 meters.

What is the bucket capacity of the Gehlmax KL 158 wheel loader?

The Gehlmax KL 158 wheel loader has a bucket capacity of 0.23 cubic meters.
