520 B Dresser 520 B Specifications & Technical Data (1985—1990)

The Dresser 520 B is a wheel loader manufactured since 1987. It has a weight of 10 tons and a maximum discharge height of 3 meters…

The Dresser 520 B is a wheel loader manufactured since 1987. It has a weight of 10 tons and a maximum discharge height of 3 meters. It can travel at a speed of 43 km/h and has a transport width of 2 meters and a transport height of 3 meters. The lifting force is 109 kN, and the bucket capacity ranges from 1 to 2 cubic meters.

Wheel Loaders Dresser 520 B

Technical specs - 520 B Dresser

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
10.24 t
Standard tyres
17.5 x 25-12PR
Bucket capacity min.
1.53 m³
Bucket capacity max.
2.1 m³
Transport width
2.39 m
Transport height
3.26 m
Travel speed
43.1 km/h
Max. discharge height
3.6 m
Lifting force
109.2 kN
Engine manuf.
Dresser
Engine type
D359T
Engine power
89.5 kW
Displacement
5.88 l
Revolutions at max torque
1200 rpm
Max. torque
499 Nm
No. of cylinders
6
Cylinder bore x stroke
102 x 120 mm

More technical details, like: bucket width, bucket capacity, steering mode, transport length, turning radius outside, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Dresser 520 B FAQ

When was the Dresser 520 B manufactured?

The Dresser 520 B was manufactured from 1985 to 1990.

How much does the Dresser 520 B wheel loader weigh?

The Dresser 520 B wheel loader weighs 10.24 tons.

What are the transport dimensions of the Dresser 520 B wheel loader?

The Dresser 520 B has a transport width of 2.39 meters and a transport height of 3.26 meters.

What is the travel speed of the Dresser 520 B wheel loader?

The Dresser 520 B has a travel speed of 43.1 km/h.

What are the standard tyre specifications of the Dresser 520 B wheel loader?

The Dresser 520 B wheel loader is equipped with standard tyres sized 17.5 x 25-12PR.

What is the power rating of the Dresser 520 B wheel loader?

The source data does not provide a power rating for the Dresser 520 B wheel loader.

What is the maximum discharge height of the Dresser 520 B?

The Dresser 520 B has a maximum discharge height of 3.6 meters.

What are the bucket capacity specifications of the Dresser 520 B wheel loader?

The Dresser 520 B wheel loader has a bucket capacity ranging from 1.53 to 2.1 cubic meters.

How much is a Dresser 520 B Wheel loader (1985u20131990) worth?

The residual value of the Dresser 520 B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
