DL420-3 Doosan DL420-3 Specifications & Technical Data (2013—2017)

The Doosan DL420-3 is a wheel loader manufactured by Doosan from 2013 to 2017. It has a weight of 23 tons and a transport length o…

The Doosan DL420-3 is a wheel loader manufactured by Doosan from 2013 to 2017. It has a weight of 23 tons and a transport length of 8.71 meters. The bucket width is 3.2 meters, and it has a maximum discharge height of 3.2 meters. The travel speed of this wheel loader is 38 km/h. It has a transport width of 3.2 meters and a transport height of 3.52 meters. The lifting force of the DL420-3 is 212 kN, and it has a turning radius outside of 6.98 meters. The bucket capacity is a minimum of 4 cubic meters. This construction machine is equipped with air conditioning.

DL420-3

Years of manufacture: 2013—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - DL420-3 Doosan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 23 t

Standard tyres: 26.5 R25 L3

Bucket width: 3.2 m

Bucket capacity min.: 4 m³

Steering mode: KL

Transport length: 8.71 m

Transport width: 3.2 m

Transport height: 3.52 m

Travel speed: 38 km/h

Max. discharge height: 3.2 m

Turning radius outside: 6.98 m

Lifting force: 212 kN

Model series: DL

Engine manuf.: Scania

Engine type: DC 13

Engine power: 264 kW

Displacement: 12.7 l

Revolutions at max torque: 1400 rpm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Doosan DL420-3 FAQ

When was the Doosan DL420-3 manufactured?

The Doosan DL420-3 was manufactured from 2013 to 2017.

How much does the Doosan DL420-3 weigh?

The Doosan DL420-3 weighs 23 tons.

What are the transport dimensions of the Doosan DL420-3 wheel loader?

The Doosan DL420-3 has a transport length of 8.71 meters, a transport width of 3.2 meters, and a transport height of 3.52 meters.

What is the travel speed of the Doosan DL420-3 wheel loader?

The Doosan DL420-3 has a travel speed of 38 km/h.

What is the standard tyre size of the Doosan DL420-3 wheel loader?

The Doosan DL420-3 wheel loader has standard tyres sized 26.5 R25 L3.

What are the maneuverability specifications of the Doosan DL420-3 wheel loader?

The Doosan DL420-3 wheel loader has an articulated-frame steering mode and an outside turning radius of 6.98 meters.

What is the lifting force of the Doosan DL420-3 wheel loader?

The Doosan DL420-3 wheel loader has a lifting force of 212 kN.

What is the maximum discharge height of the Doosan DL420-3 wheel loader?

The Doosan DL420-3 wheel loader has a maximum discharge height of 3.2 meters.

What are the specifications of the primary work tool on the Doosan DL420-3 wheel loader?

The primary work tool of the Doosan DL420-3 wheel loader has a minimum bucket capacity of 4 cubic meters and a bucket width of 3.2 meters.
