125B Clark Michigan 125B Specifications & Technical Data (1977—1985)

The Clark Michigan 125B is a wheel loader manufactured from 1977 to 1985. It has a weight of 18 tons and a bucket width of 3 meter…

The Clark Michigan 125B is a wheel loader manufactured from 1977 to 1985. It has a weight of 18 tons and a bucket width of 3 meters. The maximum discharge height is 3 meters and it can travel at a speed of 29 km/h. The transport width is 2 meters and the transport height is 3 meters. The bucket capacity ranges from a minimum of 2 cubic meters to a maximum of 3 cubic meters.

Wheel Loaders Clark Michigan 125B

Technical specs - 125B Clark Michigan

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
18.76 t
Standard tyres
23.5-25
Bucket width
3.05 m
Bucket capacity min.
2.7 m³
Bucket capacity max.
3.8 m³
Transport width
2.934 m
Transport height
3.56 m
Travel speed
29.6 km/h
Max. discharge height
3.045 m
Engine manuf.
Cummins
Engine type
VT-555-G
Engine power
165.5 kW
Displacement
9.1 l
Revolutions at max torque
2850 rpm
Max. torque
445 Nm
No. of cylinders
8
Cylinder bore x stroke
117 x 95 mm

More technical details, like: bucket capacity, steering mode, transport length, turning radius outside, lifting force, model series, dimension lxwxh, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Clark Michigan 125B FAQ

When was the Clark Michigan 125B manufactured?

The Clark Michigan 125B was manufactured from 1977 to 1985.

How much does the Clark Michigan 125B weigh?

The Clark Michigan 125B weighs 18.76 tons.

What are the transport dimensions of the Clark Michigan 125B wheel loader?

The Clark Michigan 125B has a transport width of 2.93 meters and a transport height of 3.56 meters.

What is the travel speed of the Clark Michigan 125B wheel loader?

The Clark Michigan 125B has a travel speed of 29.6 km/h.

What are the undercarriage specifications of the Clark Michigan 125B wheel loader?

The Clark Michigan 125B wheel loader is equipped with standard tyres sized 23.5-25.

What is the material handling capacity of the Clark Michigan 125B in terms of maximum discharge height?

The Clark Michigan 125B has a maximum discharge height of 3.05 meters.

What are the bucket specifications of the Clark Michigan 125B wheel loader?

The Clark Michigan 125B wheel loader has a bucket width of 3.05 meters, with a bucket capacity ranging from 2.7 to 3.8 cubic meters.

How much is a Clark Michigan 125B Wheel loader (1977u20131985) worth?

The residual value of the Clark Michigan 125B depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
