937H Changlin 937H Specifications & Technical Data (2017—2026)

The Changlin 937H is a wheel loader manufactured since 2017. It has a weight of 10.2 tons and a transport length of 6.92 meters. T…

The Changlin 937H is a wheel loader manufactured since 2017. It has a weight of 10.2 tons and a transport length of 6.92 meters. The bucket capacity is 1.7 cubic meters, and the maximum discharge height is 2.934 meters. It has a travel speed of 35 km/h and a transport width of 2.305 meters. The transport height is 3.15 meters, and the lifting force is 96 kN. The turning radius outside is 5.6 meters, and the minimum bucket capacity is 1.7 cubic meters.

Wheel Loaders Changlin 937H

Technical specs - 937H Changlin

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
10.2 t
Bucket capacity
1.7 m³
Bucket capacity min.
1.7 m³
Transport length
6.92 m
Transport width
2.305 m
Transport height
3.15 m
Travel speed
35 km/h
Max. discharge height
2.934 m
Turning radius outside
5.6 m
Lifting force
96 kN
Model series
H
Engine manuf.
Cummins
Engine type
6BT5.9-C120
Engine power
97 kW
Displacement
5.9 l
Revolutions at max torque
1500 rpm
Max. torque
440 Nm

More technical details, like: standard tyres, bucket width, bucket capacity max., steering mode, dimension lxwxh, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Changlin 937H FAQ

When was the Changlin 937H manufactured?

The Changlin 937H was first produced in 2017.

How much does the Changlin 937H wheel loader weigh?

The Changlin 937H wheel loader weighs 10.2 tons.

What are the transport dimensions of the Changlin 937H wheel loader?

The Changlin 937H has a transport length of 6.92 meters, a transport width of 2.31 meters, and a transport height of 3.15 meters.

What is the travel speed of the Changlin 937H wheel loader?

The Changlin 937H wheel loader has a travel speed of 35 km/h.

What is the outside turning radius of the Changlin 937H wheel loader?

The Changlin 937H wheel loader has an outside turning radius of 5.6 meters.

What is the lifting force of the Changlin 937H wheel loader?

The Changlin 937H wheel loader has a lifting force of 96 kN.

What is the maximum discharge height of the Changlin 937H?

The Changlin 937H has a maximum discharge height of 2.93 meters.

What is the bucket capacity of the Changlin 937H wheel loader?

The Changlin 937H wheel loader has a bucket capacity of 1.7 cubic meters.

How much is a Changlin 937H Wheel loader (2017u20132025) worth?

The residual value of the Changlin 937H depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Changlin 937H overview

Engine / Powertrain / Drivetrain

Engine and Performance

Equipped with Cummins engine. Long-time tested fixed shaft power shift T/M and 3-elements T/C are mature and reliable. Luxury cab decoration and A/C provide operator comfort. Good performance in reliability and comfort, and superior serviceability.


Best Matched Power Train

Adopted Cummins engine that features large power reservation, low oil consumption and good power performance. Internationally sourced bearing in crucial places of T/C & T/M and driving axle ensures high reliability. Long-time tested CHANGLIN brand driving axles more suitable for tough working sites.


Hydraulic system

High Efficiency Hydraulic System

Working system adopted independent hydraulic that features simple structure and high stability and low maintenance cost. Pipe joints adopted advanced sealing method ensure better sealing effect. Hydraulic tank with vacuum device ensures easy maintenance and fixing of hydraulic system.


Advanced & Reliable Brake System

Axle housing and hub reduction adopted separate structure that features low maintenance cost. Dual piping service brake with caliper disc brake ensures safety and reliability.
