988K XE Caterpillar 988K XE Specifications & Technical Data (2017—2019)

The Caterpillar 988K XE is a wheel loader manufactured from 2017 to 2019. It has a weight of 52.78 tons and a transport length of …

The Caterpillar 988K XE is a wheel loader manufactured from 2017 to 2019. It has a weight of 52.78 tons and a transport length of 12.2 meters. The bucket width is 3.9 meters and the maximum discharge height is 3.44 meters. It has a travel speed of 32.1 km/h and a transport height of 4.5 meters. The lifting force is 381 kN and the turning radius outside is 8.7 meters. The bucket capacity ranges from 4.7 to 13 cubic meters. Special equipment includes air conditioning.

Wheel Loaders Caterpillar 988K XE
Wheel Loaders Caterpillar 988K XE
Wheel Loaders Caterpillar 988K XE
Wheel Loaders Caterpillar 988K XE
Wheel Loaders Caterpillar 988K XE
Wheel Loaders Caterpillar 988K XE

Technical specs - 988K XE Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
52.78 t
Standard tyres
35/65 R 33
Bucket width
3.9 m
Bucket capacity min.
4.7 m³
Bucket capacity max.
13 m³
Steering mode
KL
Transport length
12.2 m
Transport height
4.5 m
Travel speed
32.1 km/h
Max. discharge height
3.44 m
Turning radius outside
8.7 m
Lifting force
381 kN
Model series
XE
Engine manuf.
Caterpillar
Engine type
C18 Acert
Engine power
425 kW
Displacement
18.1 l
Emission level
Tier 2/ II

More technical details, like: bucket capacity, transport width, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
Yes
Quick hitch hydr.
No
Quick hitch mech.
No

Download specalog and datasheets (PDF)

Caterpillar 988K XE FAQ

When was the Caterpillar 988K XE manufactured?

The Caterpillar 988K XE was manufactured from 2017 to 2019.

How much does the Caterpillar 988K XE wheel loader weigh?

The Caterpillar 988K XE wheel loader weighs 52.78 tons.

What are the transport dimensions of the Caterpillar 988K XE wheel loader?

The Caterpillar 988K XE has a transport length of 12.2 meters and a transport height of 4.5 meters.

What is the travel speed of the Caterpillar 988K XE wheel loader?

The Caterpillar 988K XE has a travel speed of 32.1 km/h.

What is the standard tyre size of the Caterpillar 988K XE wheel loader?

The Caterpillar 988K XE wheel loader is equipped with standard tyres sized 35/65 R 33.

What are the maneuverability specifications of the Caterpillar 988K XE wheel loader?

The Caterpillar 988K XE has an outside turning radius of 8.7 meters and uses articulated-frame steering for maneuverability.

What is the lifting force of the Caterpillar 988K XE wheel loader?

The Caterpillar 988K XE wheel loader has a lifting force of 381 kN.

What is the maximum discharge height of the Caterpillar 988K XE wheel loader?

The Caterpillar 988K XE wheel loader has a maximum discharge height of 3.44 meters.

What are the bucket specifications of the Caterpillar 988K XE wheel loader?

The Caterpillar 988K XE wheel loader has a bucket with a maximum capacity of 13 cubic meters, a minimum capacity of 4.7 cubic meters, and a width of 3.9 meters.

How much is a Caterpillar 988K XE Wheel loader (2017u20132019) worth?

The residual value of the Caterpillar 988K XE depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
