988K Caterpillar 988K Specifications & Technical Data (2017—2026)

The Caterpillar 988K is a wheel loader manufactured since 2017. It has a weight of 51.06 tons and a transport length of 11.89 mete…

The Caterpillar 988K is a wheel loader manufactured since 2017. It has a weight of 51.06 tons and a transport length of 11.89 meters. The bucket width is 4.03 meters and the maximum discharge height is 3.69 meters. It has a travel speed of 39.3 km/h and a transport height of 4.19 meters. The lifting force is 408 kN and the turning radius outside is 17.25 meters. The bucket capacity ranges from 4.7 to 13 cubic meters. Special equipment includes air conditioning and a diesel particulate filter.

988K

Years of manufacture: 2017—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 988K Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 51.06 t

Standard tyres: 35/65-R33

Bucket width: 4.03 m

Bucket capacity min.: 4.7 m³

Bucket capacity max.: 13 m³

Transport length: 11.89 m

Transport height: 4.19 m

Travel speed: 39.3 km/h

Max. discharge height: 3.69 m

Turning radius outside: 17.25 m

Lifting force: 408 kN

Engine manuf.: Caterpillar

Engine type: C18 Acert

Engine power: 425 kW

Displacement: 18.1 l

Emission level: Tier 2/ II

More technical details, like: bucket capacity, steering mode, transport width, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 988K FAQ

When was the Caterpillar 988K manufactured?

The Caterpillar 988K was first produced in 2017.

How much does the Caterpillar 988K wheel loader weigh?

The Caterpillar 988K wheel loader weighs 51.06 tons.

What are the transport dimensions of the Caterpillar 988K wheel loader?

The Caterpillar 988K has a transport length of 11.89 meters and a transport height of 4.19 meters.

What is the travel speed of the Caterpillar 988K wheel loader?

The Caterpillar 988K wheel loader has a travel speed of 39.3 km/h.

What are the undercarriage specifications of the Caterpillar 988K wheel loader?

The Caterpillar 988K wheel loader is equipped with standard tyres sized 35/65-R33.

What is the turning radius of the Caterpillar 988K wheel loader?

The Caterpillar 988K wheel loader has an outside turning radius of 17.25 meters.

What is the power rating of the Caterpillar 988K wheel loader?

The source data does not provide the power rating for the Caterpillar 988K wheel loader.

What is the material handling capacity of the Caterpillar 988K in terms of discharge height?

The Caterpillar 988K has a maximum discharge height of 3.69 meters.

What are the bucket specifications of the Caterpillar 988K wheel loader?

The Caterpillar 988K wheel loader has a bucket with a maximum capacity of 13 cubic meters, a minimum capacity of 4.7 cubic meters, and a width of 4.03 meters.
