980K Caterpillar 980K Specifications & Technical Data (2012—2015)

Model rating: 7,00 / 10

The Caterpillar 980K is a wheel loader manufactured from 2012 to 2015. It has a weight of 31.24 tons and a transport length of 9.8…

The Caterpillar 980K is a wheel loader manufactured from 2012 to 2015. It has a weight of 31.24 tons and a transport length of 9.843 meters. The bucket capacity is 4 cubic meters with a width of 3.504 meters. The maximum discharge height is 3.051 meters. It has a travel speed of 40 km/h and a transport width of 3.307 meters. The transport height is 3.809 meters. The lifting force is 238 kN and the turning radius outside is 7.183 meters. It also features air conditioning as special equipment.

980K

Years of manufacture: 2012—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 980K Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 31.24 t

Standard tyres: 29.5 R 25

Bucket width: 3.504 m

Bucket capacity: 4 m³

Bucket capacity min.: 12.2 m³

Steering mode: AL

Transport length: 9.843 m

Transport width: 3.307 m

Transport height: 3.809 m

Travel speed: 40 km/h

Max. discharge height: 3.051 m

Turning radius outside: 7.183 m

Lifting force: 238 kN

Engine manuf.: Caterpillar

Engine type: C13 Acert

Engine power: 274 kW

Displacement: 12.5 l

Revolutions at max torque: 1600 rpm

More technical details, like: bucket capacity max., model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

980K Caterpillar Specification for Europe (DE)

Caterpillar 980K FAQ

When was the Caterpillar 980K manufactured?

The Caterpillar 980K was manufactured from 2012 to 2015.

How much does the Caterpillar 980K wheel loader weigh?

The Caterpillar 980K wheel loader weighs 31.24 tons.

What are the transport dimensions of the Caterpillar 980K wheel loader?

The Caterpillar 980K wheel loader has a transport length of 9.84 meters, a transport width of 3.31 meters, and a transport height of 3.81 meters.

What is the travel speed of the Caterpillar 980K wheel loader?

The Caterpillar 980K wheel loader has a travel speed of 40 km/h.

What is the standard tyre size of the Caterpillar 980K wheel loader?

The Caterpillar 980K wheel loader is equipped with standard tyres sized 29.5 R 25.

What are the maneuverability specifications of the Caterpillar 980K wheel loader?

The Caterpillar 980K wheel loader has an outside turning radius of 7.183 meters and features all-wheel steering.

What is the lifting force of the Caterpillar 980K, as a measure related to its power ratings?

The Caterpillar 980K has a lifting force of 238 kN.

What is the material handling capacity of the Caterpillar 980K in terms of discharge height?

The Caterpillar 980K has a maximum discharge height of 3.05 meters for material handling.

What are the specifications of the bucket on the Caterpillar 980K wheel loader?

The Caterpillar 980K wheel loader has a bucket capacity of 4 mu00b3, a minimum bucket capacity of 12.2 mu00b3, and a bucket width of 3.5 meters.
