966M Caterpillar 966M Specifications & Technical Data (2019—2026)

The Caterpillar 966M is a wheel loader model manufactured by Caterpillar since 2019. It has a weight of 23.22 tons and a transport…

The Caterpillar 966M is a wheel loader model manufactured by Caterpillar since 2019. It has a weight of 23.22 tons and a transport length of 7.289 meters. The bucket capacity is 2.5 cubic meters, and it has a travel speed of 39.5 km/h. The transport width is 3.009 meters, and the transport height is 3.587 meters. The lifting force of this wheel loader is 173 kN, and the minimum bucket capacity is 9.9 cubic meters.

966M

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 966M Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 23.22 t

Bucket capacity: 2.5 m³

Bucket capacity min.: 9.9 m³

Transport length: 7.289 m

Transport width: 3.009 m

Transport height: 3.587 m

Travel speed: 39.5 km/h

Lifting force: 173 kN

Engine manuf.: Caterpillar

Engine type: C9.3

Engine power: 207 kW

Displacement: 9.3 l

Revolutions at max torque: 1700 rpm

Max. torque: 1507 Nm

Emission level: Tier 3/ IIIA

More technical details, like: standard tyres, bucket width, bucket capacity max., steering mode, max. discharge height, turning radius outside, model series, dimension lxwxh, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 966M FAQ

When was the Caterpillar 966M manufactured?

The Caterpillar 966M was first produced in 2019.

How much does the Caterpillar 966M wheel loader weigh?

The Caterpillar 966M wheel loader weighs 23.22 tons.

What are the transport dimensions of the Caterpillar 966M wheel loader?

The Caterpillar 966M has a transport length of 7.29 meters, a transport width of 3.01 meters, and a transport height of 3.59 meters.

What is the travel speed of the Caterpillar 966M wheel loader?

The Caterpillar 966M wheel loader has a travel speed of 39.5 km/h.

What is the lifting force of the Caterpillar 966M wheel loader?

The Caterpillar 966M wheel loader has a lifting force of 173 kN.

What is the bucket capacity of the Caterpillar 966M wheel loader?

The Caterpillar 966M wheel loader has a bucket capacity of 2.5 cubic meters.
