962L Caterpillar 962L Specifications & Technical Data (2019—2026)

The Caterpillar 962L is a wheel loader manufactured since 2019. It has a weight of 19.12 tons and a transport length of 8.49 meter…

The Caterpillar 962L is a wheel loader manufactured since 2019. It has a weight of 19.12 tons and a transport length of 8.49 meters. The bucket capacity is 4.4 cubic meters, and the maximum discharge height is 3.01 meters. It has a travel speed of 39.5 km/h and a transport width of 2.82 meters. The transport height is 3.74 meters, and the lifting force is 146 kN. The turning radius outside is 5.98 meters, and it is equipped with air conditioning.

962L

Years of manufacture: 2019—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 962L Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 19.12 t

Standard tyres: 23.5R25

Bucket capacity: 4.4 m³

Bucket capacity min.: 4.4 m³

Transport length: 8.49 m

Transport width: 2.82 m

Transport height: 3.74 m

Travel speed: 39.5 km/h

Max. discharge height: 3.01 m

Turning radius outside: 5.98 m

Lifting force: 146 kN

Engine manuf.: Caterpillar

Engine type: C 7.1 Acert

Engine power: 185 kW

Displacement: 7.01 l

Max. torque: 984 Nm

Cylinder bore x stroke: 105x135 mm

Emission level: Tier 3/ IIIA

More technical details, like: bucket width, bucket capacity max., steering mode, model series, dimension lxwxh, revolutions at max torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 962L FAQ

When was the Caterpillar 962L manufactured?

The Caterpillar 962L was first produced in 2019.

How much does the Caterpillar 962L wheel loader weigh?

The Caterpillar 962L wheel loader weighs 19.12 tons.

What are the transport dimensions of the Caterpillar 962L wheel loader?

The Caterpillar 962L has a transport length of 8.49 meters, a transport width of 2.82 meters, and a transport height of 3.74 meters.

What is the travel speed of the Caterpillar 962L wheel loader?

The Caterpillar 962L has a travel speed of 39.5 km/h.

What is the standard tyre size of the Caterpillar 962L wheel loader?

The Caterpillar 962L wheel loader is equipped with standard tyres sized 23.5R25.

What is the outside turning radius of the Caterpillar 962L wheel loader?

The Caterpillar 962L has an outside turning radius of 5.98 meters.

What is the lifting force rating of the Caterpillar 962L wheel loader?

The Caterpillar 962L wheel loader has a lifting force of 146 kN.

What is the maximum discharge height of the Caterpillar 962L wheel loader for material handling?

The Caterpillar 962L wheel loader has a maximum discharge height of 3.01 meters for material handling.

What is the bucket capacity of the Caterpillar 962L wheel loader?

The Caterpillar 962L wheel loader has a bucket capacity of 4.4 cubic meters.
