950K Caterpillar 950K Specifications & Technical Data (2012—2015)

Model rating: 10,00 / 10

The Caterpillar 950K is a wheel loader manufactured from 2012 to 2015. It has a weight of 18.5 tons and a bucket capacity ranging …

The Caterpillar 950K is a wheel loader manufactured from 2012 to 2015. It has a weight of 18.5 tons and a bucket capacity ranging from 2.5 to 9.2 cubic meters, with a bucket width of 2.952 meters. The maximum discharge height is 4.021 meters. It has a travel speed of 37.9 km/h and a transport width of 2.719 meters. The transport height is 3.356 meters, and the turning radius outside is 5.952 meters. Special equipment includes air conditioning.

950K

Years of manufacture: 2012—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 950K Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 18.5 t

Standard tyres: 23.5x25

Bucket width: 2.952 m

Bucket capacity: 3.3 m³

Bucket capacity min.: 2.5 m³

Bucket capacity max.: 9.2 m³

Steering mode: KL

Transport width: 2.719 m

Transport height: 3.356 m

Travel speed: 37.9 km/h

Max. discharge height: 4.021 m

Turning radius outside: 5.952 m

Lifting force: 161 kN

Engine manuf.: Caterpillar

Engine type: C7 Acert

Engine power: 158 kW

Displacement: 7 l

Revolutions at max torque: 1900 rpm

More technical details, like: transport length, model series, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 950K FAQ

When was the Caterpillar 950K manufactured?

The Caterpillar 950K was manufactured from 2012 to 2015.

How much does the Caterpillar 950K wheel loader weigh?

The Caterpillar 950K wheel loader weighs 18.5 tons.

What are the transport dimensions of the Caterpillar 950K?

The Caterpillar 950K has a transport width of 2.72 meters and a transport height of 3.36 meters.

What is the travel speed of the Caterpillar 950K wheel loader?

The Caterpillar 950K wheel loader has a travel speed of 37.9 km/h.

What are the standard tyres of the Caterpillar 950K?

The Caterpillar 950K is equipped with standard tyres sized 23.5x25.

What are the maneuverability specifications of the Caterpillar 950K wheel loader?

The Caterpillar 950K wheel loader has an articulated-frame steering system and an outside turning radius of 5.952 meters.

What is the lifting force of the Caterpillar 950K wheel loader?

The Caterpillar 950K wheel loader has a lifting force of 161 kN.

What is the maximum discharge height of the Caterpillar 950K?

The Caterpillar 950K has a maximum discharge height of 4.02 meters.

What are the specifications of the bucket on the Caterpillar 950K wheel loader?

The Caterpillar 950K wheel loader has a bucket with a capacity of 3.3 cubic meters, a maximum capacity of 9.2 cubic meters, a minimum capacity of 2.5 cubic meters, and a width of 2.95 meters.
