918M Caterpillar 918M Specifications & Technical Data (2016—2020)

The Caterpillar 918M is a wheel loader manufactured from 2016 to 2020. It has a weight of 9.47 tons and a transport length of 6.65…

The Caterpillar 918M is a wheel loader manufactured from 2016 to 2020. It has a weight of 9.47 tons and a transport length of 6.65 meters. The bucket capacity is 1.4 cubic meters with a width of 2.4 meters. The maximum discharge height is 2.84 meters. It has a travel speed of 40 km/h and a transport width of 2.26 meters. The transport height is 3.3 meters. The lifting force is 83.16 kN. The turning radius outside is 5.41 meters. The minimum bucket capacity is 1.4 cubic meters.

918M

Years of manufacture: 2016—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 918M Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 9.47 t

Standard tyres: 17.5-25 12PR

Bucket width: 2.4 m

Bucket capacity: 1.4 m³

Bucket capacity min.: 1.4 m³

Steering mode: KL

Transport length: 6.65 m

Transport width: 2.26 m

Transport height: 3.3 m

Travel speed: 40 km/h

Max. discharge height: 2.84 m

Turning radius outside: 5.41 m

Lifting force: 83.16 kN

Engine manuf.: Caterpillar

Engine type: C4.4 Acert

Engine power: 84 kW

Displacement: 4.4 l

Max. torque: 490 Nm

Cylinder bore x stroke: 105x127 mm

Emission level: Tier 4 f

More technical details, like: bucket capacity max., model series, dimension lxwxh, revolutions at max torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

918M Caterpillar Specification for Europe (EN)

Caterpillar 918M FAQ

When was the Caterpillar 918M manufactured?

The Caterpillar 918M was manufactured from 2016 to 2020.

How much does the Caterpillar 918M wheel loader weigh?

The Caterpillar 918M wheel loader weighs 9.47 tons.

What are the transport dimensions of the Caterpillar 918M wheel loader?

The Caterpillar 918M has a transport length of 6.65 meters, a transport width of 2.26 meters, and a transport height of 3.3 meters.

What is the travel speed of the Caterpillar 918M wheel loader?

The Caterpillar 918M has a travel speed of 40 km/h.

What are the undercarriage specifications of the Caterpillar 918M wheel loader?

The Caterpillar 918M wheel loader is equipped with standard tyres sized 17.5-25 12PR.

What are the maneuverability specifications of the Caterpillar 918M wheel loader?

The Caterpillar 918M wheel loader has an outside turning radius of 5.41 meters and uses articulated-frame steering.

What is the lifting force of the Caterpillar 918M wheel loader?

The Caterpillar 918M wheel loader has a lifting force of 83.16 kN.

What is the maximum discharge height of the Caterpillar 918M?

The Caterpillar 918M has a maximum discharge height of 2.84 meters.

What are the bucket specifications of the Caterpillar 918M wheel loader?

The Caterpillar 918M wheel loader has a bucket capacity of 1.4 cubic meters, a minimum bucket capacity of 1.4 cubic meters, and a bucket width of 2.4 meters.
