907 Caterpillar 907 Specifications & Technical Data (2022—2026)

The Caterpillar 907 is a wheel loader manufactured since 2022. With a weight of 5.79 tons, it has a compact design with a transpor…

The Caterpillar 907 is a wheel loader manufactured since 2022. With a weight of 5.79 tons, it has a compact design with a transport length of 5.469 meters and a transport width of 1.84 meters. The machine is equipped with a swing loader and has a bucket capacity of 1.05 cubic meters, with a bucket width of 2.03 meters. It can reach a maximum discharge height of 2.478 meters and has a travel speed of 20 km/h. The transport height is 2.586 meters and it has a turning radius outside of 4.49 meters. The bucket capacity remains constant at 1.05 cubic meters.

907

Years of manufacture: 2022—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 907 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.79 t

Standard tyres: 405/70 R18

Bucket width: 2.03 m

Bucket capacity: 1.05 m³

Bucket capacity min.: 1.05 m³

Steering mode: KL

Transport length: 5.469 m

Transport width: 1.84 m

Transport height: 2.586 m

Travel speed: 20 km/h

Max. discharge height: 2.478 m

Turning radius outside: 4.49 m

Engine manuf.: Caterpillar

Engine type: C2.8 DIT

Engine power: 55.4 kW

Displacement: 2.8 l

Revolutions at max torque: 2400 rpm

Max. torque: 300 Nm

Cylinder bore x stroke: 90x110 mm

Emission level: EU V

More technical details, like: bucket capacity max., lifting force, model series, dimension lxwxh, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: Yes
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 907 FAQ

When was the Caterpillar 907 manufactured?

The Caterpillar 907 was first produced in 2022.

How much does the Caterpillar 907 wheel loader weigh?

The Caterpillar 907 wheel loader weighs 5.79 tons.

What are the transport dimensions of the Caterpillar 907 wheel loader?

The Caterpillar 907 wheel loader has a transport length of 5.47 meters, a transport width of 1.84 meters, and a transport height of 2.59 meters.

What is the travel speed of the Caterpillar 907 wheel loader?

The Caterpillar 907 wheel loader has a travel speed of 20 km/h.

What are the undercarriage tyre specifications of the Caterpillar 907 wheel loader?

The Caterpillar 907 wheel loader is equipped with standard tyres sized 405/70 R18.

What are the maneuverability specifications of the Caterpillar 907 wheel loader?

The Caterpillar 907 wheel loader has an articulated-frame steering mode and an outside turning radius of 4.49 meters.

What is the maximum discharge height of the Caterpillar 907?

The Caterpillar 907 has a maximum discharge height of 2.48 meters.

What are the bucket specifications of the Caterpillar 907 wheel loader?

The Caterpillar 907 wheel loader has a bucket capacity of 1.05 cubic meters, a minimum bucket capacity of 1.05 cubic meters, and a bucket width of 2.03 meters.
