906 H Caterpillar 906 H Specifications & Technical Data (2009—2013)

The Caterpillar 906 H is a wheel loader manufactured from 2009 to 2013. It has a weight of 5.63 tons and a transport length of 5.5…

The Caterpillar 906 H is a wheel loader manufactured from 2009 to 2013. It has a weight of 5.63 tons and a transport length of 5.58 meters. The bucket capacity is 1.2 cubic meters, with a bucket width of 1.88 meters. The maximum discharge height is 2.39 meters. It has a travel speed of 35 km/h and a transport width of 1.84 meters. The transport height is 2.46 meters and the turning radius outside is 4.44 meters. The bucket capacity ranges from 0.75 to 1.2 cubic meters.

906 H

Years of manufacture: 2009—2013

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 906 H Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.63 t

Standard tyres: 405/70 R18

Bucket width: 1.88 m

Bucket capacity: 1.2 m³

Bucket capacity min.: 0.75 m³

Bucket capacity max.: 1.2 m³

Transport length: 5.58 m

Transport width: 1.84 m

Transport height: 2.46 m

Travel speed: 35 km/h

Max. discharge height: 2.39 m

Turning radius outside: 4.44 m

Engine manuf.: CAT

Engine type: C3.4

Engine power: 52 kW

Displacement: 3.3 l

Cylinder bore x stroke: 94x120 mm

More technical details, like: steering mode, lifting force, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

Caterpillar 906 H FAQ

When was the Caterpillar 906 H manufactured?

The Caterpillar 906 H was manufactured from 2009 to 2013.

How much does the Caterpillar 906 H weigh?

The Caterpillar 906 H weighs 5.63 tons.

What are the transport dimensions of the Caterpillar 906 H wheel loader?

The Caterpillar 906 H has a transport length of 5.58 meters, a transport width of 1.84 meters, and a transport height of 2.46 meters.

What is the travel speed of the Caterpillar 906 H wheel loader?

The Caterpillar 906 H has a travel speed of 35 km/h.

What are the undercarriage specifications of the Caterpillar 906 H wheel loader?

The Caterpillar 906 H wheel loader is equipped with standard tyres sized 405/70 R18.

What is the turning radius of the Caterpillar 906 H wheel loader?

The Caterpillar 906 H has an outside turning radius of 4.44 meters.

What is the maximum discharge height of the Caterpillar 906 H?

The Caterpillar 906 H has a maximum discharge height of 2.39 meters.

What are the bucket specifications of the Caterpillar 906 H wheel loader?

The Caterpillar 906 H wheel loader has a bucket capacity ranging from 0.75 to 1.2 cubic meters, with a maximum capacity of 1.2 cubic meters and a bucket width of 1.88 meters.
