903C 2 Caterpillar 903C 2 Specifications & Technical Data (2015—2019)

The Caterpillar 903C 2 is a wheel loader manufactured by Caterpillar from 2015 to 2019. It has a weight of 4.11 tons and a transpo…

The Caterpillar 903C 2 is a wheel loader manufactured by Caterpillar from 2015 to 2019. It has a weight of 4.11 tons and a transport length of 4.695 meters. The bucket capacity is 0.6 cubic meters with a bucket width of 1.708 meters. The maximum discharge height is 2.29 meters and it has a travel speed of 16 km/h. The transport width and height are both 1.708 meters and 2.51 meters respectively. The turning radius outside is 3.94 meters. The machine is equipped with special features such as air conditioning and a diesel particulate filter.

903C 2

Years of manufacture: 2015—2019

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 903C 2 Caterpillar

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.11 t

Standard tyres: 15.5-16-5 12 PR

Bucket width: 1.708 m

Bucket capacity: 0.6 m³

Bucket capacity min.: 0.6 m³

Steering mode: KL

Transport length: 4.695 m

Transport width: 1.708 m

Transport height: 2.51 m

Travel speed: 16 km/h

Max. discharge height: 2.29 m

Turning radius outside: 3.94 m

Engine manuf.: Caterpillar

Engine type: C2.4

Engine power: 31 kW

Displacement: 2.4 l

Cylinder bore x stroke: 87x102 mm

Emission level: Tier 4 f

More technical details, like: bucket capacity max., lifting force, model series, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download specalog and datasheets (PDF)

903C 2 Caterpillar Specification for Europe (EN)

Caterpillar 903C 2 FAQ

When was the Caterpillar 903C 2 manufactured?

The Caterpillar 903C 2 was manufactured from 2015 to 2019.

How much does the Caterpillar 903C 2 wheel loader weigh?

The Caterpillar 903C 2 wheel loader weighs 4.11 tons.

What are the transport dimensions of the Caterpillar 903C 2 wheel loader?

The Caterpillar 903C 2 has a transport length of 4.7 meters, a transport width of 1.71 meters, and a transport height of 2.51 meters.

What is the travel speed of the Caterpillar 903C 2 wheel loader?

The Caterpillar 903C 2 has a travel speed of 16 km/h.

What are the tyre specifications of the Caterpillar 903C 2 wheel loader?

The Caterpillar 903C 2 wheel loader is equipped with standard tyres sized 15.5-16-5 12 PR.

What are the maneuverability specifications of the Caterpillar 903C 2 wheel loader?

The Caterpillar 903C 2 has an articulated-frame steering system and an outside turning radius of 3.94 meters.

What is the maximum discharge height of the Caterpillar 903C 2?

The Caterpillar 903C 2 has a maximum discharge height of 2.29 meters.

What are the specifications of the bucket on the Caterpillar 903C 2 wheel loader?

The Caterpillar 903C 2 wheel loader has a bucket with a capacity of 0.6 cubic meters, a minimum capacity of 0.6 cubic meters, and a width of 1.71 meters.
