PX 45 Cast Group PX 45 Specifications & Technical Data (2013—2015)

The Cast Group PX 45 is a wheel loader manufactured from 2013 to 2015. It has a weight of 1.6 tons and a transport length of 2.48 …

The Cast Group PX 45 is a wheel loader manufactured from 2013 to 2015. It has a weight of 1.6 tons and a transport length of 2.48 meters. The maximum discharge height is 3.3 meters, and the transport width is 1.35 meters. The transport height is 2.2 meters, and it has a lifting force of 1400 kN. The turning radius outside is 2.2 meters, and it is equipped with a quick hitch mechanism and telescopic special equipment.

PX 45

Years of manufacture: 2013—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - PX 45 Cast Group

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.6 t

Standard tyres: PR10/16.5

Transport length: 2.48 m

Transport width: 1.35 m

Transport height: 2.2 m

Travel speed: 16 km/h

Max. discharge height: 3.3 m

Turning radius outside: 2.2 m

Lifting force: 1400 kN

Model series: PX

Engine manuf.: Isuzu

Engine type: 3 CE 1

Engine power: 28 kW

Displacement: 1.642 l

More technical details, like: bucket width, bucket capacity, bucket capacity min., bucket capacity max., steering mode, dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: Yes
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

PX 45 Cast Group Specification for Europe (DE)

Cast Group PX 45 FAQ

When was the Cast Group PX 45 manufactured?

The Cast Group PX 45 was manufactured from 2013 to 2015.

How much does the Cast Group PX 45 weigh?

The Cast Group PX 45 weighs 1.6 tons.

What are the transport dimensions of the Cast Group PX 45 wheel loader?

The Cast Group PX 45 has a transport length of 2.48 meters, a transport width of 1.35 meters, and a transport height of 2.2 meters.

What is the travel speed of the Cast Group PX 45 wheel loader?

The Cast Group PX 45 wheel loader has a travel speed of 16 km/h.

What are the undercarriage specifications of the Cast Group PX 45 wheel loader?

The Cast Group PX 45 wheel loader is equipped with standard tyres sized PR10/16.5.

What is the turning radius of the Cast Group PX 45 wheel loader?

The Cast Group PX 45 has an outside turning radius of 2.2 meters.

What is the lifting force of the Cast Group PX 45 wheel loader?

The Cast Group PX 45 wheel loader has a lifting force of 1400 kN.

What is the maximum discharge height of the Cast Group PX 45?

The Cast Group PX 45 has a maximum discharge height of 3.3 meters.

How much is a Cast Group PX 45 Wheel loader (2013u20132015) worth?

The residual value of the Cast Group PX 45 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
