W-20 Case W-20 Specifications & Technical Data (1977—2020)

The Case W-20 is a wheel loader manufactured since 1977. It has a weight of 21.183 tons and a transport length of 6.12 meters. The…

The Case W-20 is a wheel loader manufactured since 1977. It has a weight of 21.183 tons and a transport length of 6.12 meters. The travel speed is 37.5 km/h, and the transport width is 2.4 meters. The turning radius outside is 9.93 meters. The bucket capacity ranges from 1.2 to 1.9 cubic meters.

Wheel Loaders Case W-20

Technical specs - W-20 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
21.183 t
Standard tyres
17.5 x 25 12
Bucket capacity min.
1.2 m³
Bucket capacity max.
1.9 m³
Transport length
6.12 m
Transport width
2.4 m
Travel speed
37.5 km/h
Turning radius outside
9.93 m
Engine manuf.
Case
Engine type
A504BD
Engine power
82 kW
Displacement
8.26 l
Max. torque
375 Nm
No. of cylinders
6
Cylinder bore x stroke
117x127 mm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

Case W-20 FAQ

When was the Case W-20 manufactured?

The Case W-20 was manufactured from 1977 to 2020.

How much does the Case W-20 wheel loader weigh?

The Case W-20 wheel loader weighs 21.18 tons.

What are the transport dimensions of the Case W-20 wheel loader?

The Case W-20 has a transport length of 6.12 meters and a transport width of 2.4 meters.

What is the travel speed of the Case W-20 wheel loader?

The Case W-20 has a travel speed of 37.5 km/h.

What are the undercarriage specifications of the Case W-20 wheel loader?

The Case W-20 wheel loader is equipped with standard tyres sized 17.5 x 25 12.

What is the turning radius of the Case W-20 wheel loader?

The Case W-20 wheel loader has an outside turning radius of 9.93 meters.

What are the bucket capacity specifications of the Case W-20 wheel loader?

The Case W-20 wheel loader has a bucket capacity ranging from 1.2 to 1.9 cubic meters.
