521 E Case 521 E Specifications & Technical Data (2009—2012)

The Case 521 E is a wheel loader manufactured from 2009 to 2012. It has a weight of 10.38 tons and a transport length of 6.83 mete…

The Case 521 E is a wheel loader manufactured from 2009 to 2012. It has a weight of 10.38 tons and a transport length of 6.83 meters. The bucket capacity is 1.7 cubic meters, with a bucket width of 2.49 meters. The maximum discharge height is 2.62 meters, and it has a travel speed of 39 km/h. The transport width is 2.48 meters, and the transport height is 3.28 meters. The turning radius outside is 11.02 meters. Special equipment includes air conditioning.

521 E

Years of manufacture: 2009—2012

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 521 E Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 10.38 t

Standard tyres: 20.5x25 L 3

Bucket width: 2.49 m

Bucket capacity: 1.7 m³

Bucket capacity min.: 1.9 m³

Bucket capacity max.: 1.9 m³

Steering mode: AL

Transport length: 6.83 m

Transport width: 2.48 m

Transport height: 3.28 m

Travel speed: 39 km/h

Max. discharge height: 2.62 m

Turning radius outside: 11.02 m

Model series: E

Engine manuf.: Case

Engine type: 445 TA/EGE

Engine power: 142 kW

Displacement: 4.5 l

Revolutions at max torque: 1800 rpm

Emission level: III

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Case 521 E FAQ

When was the Case 521 E manufactured?

The Case 521 E was manufactured from 2009 to 2012.

How much does the Case 521 E wheel loader weigh?

The Case 521 E wheel loader weighs 10.38 tons.

What are the transport dimensions of the Case 521 E wheel loader?

The Case 521 E has a transport length of 6.83 meters, a transport width of 2.48 meters, and a transport height of 3.28 meters.

What is the travel speed of the Case 521 E wheel loader?

The Case 521 E wheel loader has a travel speed of 39 km/h.

What are the undercarriage specifications of the Case 521 E wheel loader?

The Case 521 E wheel loader is equipped with standard tyres sized 20.5x25 L 3.

What are the maneuverability specifications of the Case 521 E wheel loader?

The Case 521 E wheel loader has an outside turning radius of 11.02 meters and features all-wheel steering.

What is the material handling capacity of the Case 521 E in terms of discharge height?

The Case 521 E has a maximum discharge height of 2.62 meters.

What are the specifications of the bucket on the Case 521 E wheel loader?

The Case 521 E wheel loader has a bucket with a capacity of 1.7 cubic meters, a maximum capacity of 1.9 cubic meters, a minimum capacity of 1.9 cubic meters, and a width of 2.49 meters.
