321 E Case 321 E Specifications & Technical Data (2006—2008)

The Case 321 E is a wheel loader manufactured from 2006 to 2008. It has a weight of 5.75 tons and a transport length of 5.75 meter…

The Case 321 E is a wheel loader manufactured from 2006 to 2008. It has a weight of 5.75 tons and a transport length of 5.75 meters. The bucket capacity is 1.2 cubic meters, with a bucket width of 2.1 meters. The maximum discharge height is 3.46 meters, and it has a travel speed of 35 km/h. The transport width is 2.1 meters, and the transport height is 2.81 meters. It has a lifting force of 57 kN and a turning radius outside of 4.45 meters. Special equipment includes a quick hitch mechanism.

321 E

Years of manufacture: 2006—2008

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 321 E Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.75 t

Standard tyres: 405/70 R 20

Bucket width: 2.1 m

Bucket capacity: 1.2 m³

Bucket capacity min.: 1.2 m³

Steering mode: KL

Transport length: 5.75 m

Transport width: 2.1 m

Transport height: 2.81 m

Travel speed: 35 km/h

Max. discharge height: 3.46 m

Turning radius outside: 4.45 m

Lifting force: 57 kN

Model series: E

Engine manuf.: Deutz

Engine type: BF4M2011

Engine power: 56 kW

Displacement: 3.2 l

Revolutions at max torque: 2500 rpm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

321 E Case Specification for Asia Pacific (CN)

Case 321 E FAQ

When was the Case 321 E manufactured?

The Case 321 E was manufactured from 2006 to 2008.

How much does the Case 321 E wheel loader weigh?

The Case 321 E wheel loader weighs 5.75 tons.

What are the transport dimensions of the Case 321 E wheel loader?

The Case 321 E wheel loader has a transport length of 5.75 meters, a transport width of 2.1 meters, and a transport height of 2.81 meters.

What is the travel speed of the Case 321 E wheel loader?

The travel speed of the Case 321 E wheel loader is 35 km/h.

What are the standard tyre specifications of the Case 321 E wheel loader?

The Case 321 E wheel loader is equipped with standard tyres sized 405/70 R 20.

What are the maneuverability specifications of the Case 321 E wheel loader?

The Case 321 E wheel loader has an articulated-frame steering mode and an outside turning radius of 4.45 meters.

What is the lifting force, as the available power-related metric, of the Case 321 E wheel loader?

The Case 321 E wheel loader has a lifting force of 57 kN.

What is the maximum discharge height of the Case 321 E wheel loader?

The Case 321 E wheel loader has a maximum discharge height of 3.46 meters.

What are the bucket specifications of the Case 321 E wheel loader?

The Case 321 E wheel loader has a bucket capacity of 1.2 cubic meters, a minimum bucket capacity of 1.2 cubic meters, and a bucket width of 2.1 meters.
