21F Case 21F Specifications & Technical Data (2014—2020)

The Case 21F is a wheel loader manufactured from 2014 to 2020. It has a weight of 5.3 tons and a transport length of 5.334 meters.…

The Case 21F is a wheel loader manufactured from 2014 to 2020. It has a weight of 5.3 tons and a transport length of 5.334 meters. The bucket capacity is 0.7 cubic meters, with a bucket width of 1.9 meters. The maximum discharge height is 3.243 meters, and it has a travel speed of 20 km/h. The transport width is 1.846 meters, and the transport height is 2.711 meters. It has a lifting force of 42.6 kN and a turning radius outside of 4.15 meters. Special equipment includes a quick hitch hydraulic mechanism.

21F

Years of manufacture: 2014—2020

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 21F Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.3 t

Standard tyres: 335/80 R 18

Bucket width: 1.9 m

Bucket capacity: 0.7 m³

Bucket capacity min.: 0.7 m³

Steering mode: KL

Transport length: 5.334 m

Transport width: 1.846 m

Transport height: 2.711 m

Travel speed: 20 km/h

Max. discharge height: 3.243 m

Turning radius outside: 4.15 m

Lifting force: 42.6 kN

Model series: F

Engine manuf.: CNH

Engine type: F5H

Engine power: 43 kW

Displacement: 3.4 l

Revolutions at max torque: 2100 rpm

Max. torque: 245 Nm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Case 21F FAQ

When was the Case 21F manufactured?

The Case 21F was manufactured from 2014 to 2020.

How much does the Case 21F wheel loader weigh?

The Case 21F wheel loader weighs 5.3 tons.

What are the transport dimensions of the Case 21F wheel loader?

The Case 21F wheel loader has a transport length of 5.33 meters, a transport width of 1.85 meters, and a transport height of 2.71 meters.

What is the travel speed of the Case 21F wheel loader?

The Case 21F wheel loader has a travel speed of 20 km/h.

What is the standard tyre size of the Case 21F wheel loader?

The Case 21F wheel loader comes equipped with standard tyres sized 335/80 R 18.

What are the maneuverability specifications of the Case 21F wheel loader?

The Case 21F wheel loader has an articulated-frame steering system and an outside turning radius of 4.15 meters.

What is the power rating of the Case 21F wheel loader?

The power rating of the Case 21F wheel loader is not provided in the available data.

What is the maximum discharge height of the Case 21F wheel loader?

The Case 21F wheel loader has a maximum discharge height of 3.24 meters.

What are the specifications of the bucket on the Case 21F wheel loader?

The Case 21F wheel loader has a bucket capacity of 0.7 cubic meters, a minimum bucket capacity of 0.7 cubic meters, and a bucket width of 1.9 meters.
