121 E S-3 Case 121 E S-3 Specifications & Technical Data (2008—2014)

The Case 121 E S-3 is a wheel loader manufactured from 2008 to 2014. It has a weight of 5.05 tons and a transport length of 5.43 m…

The Case 121 E S-3 is a wheel loader manufactured from 2008 to 2014. It has a weight of 5.05 tons and a transport length of 5.43 meters. The bucket capacity ranges from 0.8 to 0.9 cubic meters, with a bucket width of 2.05 meters. The maximum discharge height is 3.3 meters. It has a travel speed of 20 km/h and a transport width of 1.91 meters. The transport height is 2.82 meters, and the turning radius outside is 4.25 meters. Special equipment includes a quick hitch mechanism.

121 E S-3

Years of manufacture: 2008—2014

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 121 E S-3 Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.05 t

Standard tyres: 12.5x20

Bucket width: 2.05 m

Bucket capacity: 0.8 m³

Bucket capacity min.: 0.8 m³

Bucket capacity max.: 0.9 m³

Steering mode: KL

Transport length: 5.43 m

Transport width: 1.91 m

Transport height: 2.82 m

Travel speed: 20 km/h

Max. discharge height: 3.3 m

Turning radius outside: 4.25 m

Lifting force: 50.5 kN

Model series: E

Engine manuf.: CNH

Engine type: F5C-E9454G

Engine power: 48 kW

Displacement: 3.2 l

Revolutions at max torque: 2300 rpm

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: No
Quick hitch mech.: Yes

Download datasheets (PDF)

Case 121 E S-3 FAQ

When was the Case 121 E S-3 manufactured?

The Case 121 E S-3 was manufactured from 2008 to 2014.

How much does the Case 121 E S-3 weigh?

The Case 121 E S-3 weighs 5.05 tons.

What are the transport dimensions of the Case 121 E S-3 wheel loader?

The Case 121 E S-3 has a transport length of 5.43 meters, a transport width of 1.91 meters, and a transport height of 2.82 meters.

What is the travel speed of the Case 121 E S-3 wheel loader?

The travel speed of the Case 121 E S-3 wheel loader is 20 km/h.

What is the standard tyre size of the Case 121 E S-3 wheel loader?

The Case 121 E S-3 wheel loader has standard tyres sized 12.5x20.

What are the maneuverability specifications of the Case 121 E S-3 wheel loader?

The Case 121 E S-3 has an articulated-frame steering mode and an outside turning radius of 4.25 meters.

What is the lifting force of the Case 121 E S-3 wheel loader?

The Case 121 E S-3 wheel loader has a lifting force of 50.5 kN.

What is the maximum discharge height of the Case 121 E S-3?

The Case 121 E S-3 has a maximum discharge height of 3.3 meters.

What are the bucket specifications of the Case 121 E S-3 wheel loader?

The Case 121 E S-3 wheel loader has a bucket capacity ranging from 0.8 to 0.9 cubic meters, with a bucket width of 2.05 meters.
