1021 G Case 1021 G Specifications & Technical Data (2021—2026)

The Case 1021G is a wheel loader manufactured by Case since 2021. It has a weight of 27.06 tons and a transport length of 9.17 met…

The Case 1021G is a wheel loader manufactured by Case since 2021. It has a weight of 27.06 tons and a transport length of 9.17 meters. The bucket capacity is 4.2 cubic meters, with a bucket width of 3.05 meters. The maximum discharge height is 2.94 meters. It has a travel speed of 38 km/h and a transport width of 2.99 meters. The transport height is 3.57 meters and the turning radius outside is 7.09 meters. The bucket capacity remains constant at 4.2 cubic meters. It is equipped with air conditioning and a diesel particulate filter.

1021 G

Years of manufacture: 2021—2026

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - 1021 G Case

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 27.06 t

Standard tyres: 26.5 R 25 L5

Bucket width: 3.05 m

Bucket capacity: 4.2 m³

Bucket capacity min.: 4.2 m³

Steering mode: KL

Transport length: 9.17 m

Transport width: 2.99 m

Transport height: 3.57 m

Travel speed: 38 km/h

Max. discharge height: 2.94 m

Turning radius outside: 7.09 m

Model series: G

Engine manuf.: CNH

Engine type: Cursor 9

Engine power: 239 kW

Displacement: 8.7 l

Revolutions at max torque: 1800 rpm

Max. torque: 1479 Nm

No. of cylinders: 6

Emission level: V

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: Yes
Swing loader: No
telescopic: No
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: No

Download datasheets (PDF)

Case 1021 G FAQ

When was the Case 1021 G manufactured?

The Case 1021 G was first produced in 2021.

How much does the Case 1021 G wheel loader weigh?

The Case 1021 G wheel loader weighs 27.06 tons.

What are the transport dimensions of the Case 1021 G wheel loader?

The Case 1021 G has a transport length of 9.17 meters, a transport width of 2.99 meters, and a transport height of 3.57 meters.

What is the travel speed of the Case 1021 G wheel loader?

The Case 1021 G wheel loader has a travel speed of 38 km/h.

What are the standard tyre specifications of the Case 1021 G wheel loader?

The Case 1021 G wheel loader is equipped with standard tyres sized 26.5 R 25 L5.

What are the maneuverability specifications of the Case 1021 G wheel loader?

The Case 1021 G wheel loader has an articulated-frame steering mode and an outside turning radius of 7.09 meters.

What is the maximum discharge height of the Case 1021 G?

The Case 1021 G has a maximum discharge height of 2.94 meters.

What are the bucket specifications of the Case 1021 G wheel loader?

The Case 1021 G wheel loader has a bucket capacity of 4.2 cubic meters, a minimum bucket capacity of 4.2 cubic meters, and a bucket width of 3.05 meters.
