L85 Bobcat L85 Specifications & Technical Data (2021—2026)

The Bobcat L85 is a wheel loader manufactured since 2021. It has a weight of 4.674 tons and a transport length of 5.4 meters. The …

The Bobcat L85 is a wheel loader manufactured since 2021. It has a weight of 4.674 tons and a transport length of 5.4 meters. The bucket capacity is 0.8 cubic meters with a width of 1.9 meters. The maximum discharge height is 2.5 meters. It has a travel speed of 20 km/h and a transport width and height of 1.9 meters and 2.4 meters respectively. The lifting force is 36.9 kN and the turning radius outside is 3.8 meters. The maximum bucket capacity is 1.2 cubic meters and the minimum is 0.6 cubic meters.

Visit Bobcat live at

Technical specs - L85 Bobcat

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
4.674 t
Standard tyres
335/80 R18
Bucket width
1.9 m
Bucket capacity
0.8 m³
Bucket capacity min.
0.6 m³
Bucket capacity max.
1.2 m³
Steering mode
KL
Transport length
5.4 m
Transport width
1.9 m
Transport height
2.4 m
Travel speed
20 km/h
Max. discharge height
2.5 m
Turning radius outside
3.8 m
Lifting force
36.9 kN
Model series
L
Engine manuf.
Bobcat
Engine type
2.4L
Engine power
50.7 kW
Displacement
2.4 l
Revolutions at max torque
2600 rpm
Emission level
V

More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter
No
Swing loader
No
telescopic
No
Aircondition
No
Quick hitch hydr.
No
Quick hitch mech.
No

Download datasheets (PDF)

What Bobcat says about this machine

What are the key characteristics of this model?

The powerful Bobcat engine and hydraulics ensure the high performance of the compact wheel loader, which is also characterized by excellent stability, excellent breakout, pushing and pulling forces and a large selection of Bobcat attachments.

What type of job is the machine best suited to do?

The machine is ideally suited for all earthmoving and loading work in construction, landscaping, rental, commercial applications, waste management, recycling or agriculture.

Can you name features that differentiates this machine from others?

One feature that sets the L85 apart from the industry is advanced implement control. This groundbreaking system allows you to switch control modes with the push of a button, so that engine speed (and maximum auxiliary hydraulics) and machine travel speed can be independently controlled. Even the most complicated attachments can be controlled intuitively and efficiently via the 7-pin connection.

What type of companies is this machine designed for?

It is just as suitable for construction, landscaping, rental, commercial applications, waste management, recycling or agriculture as it is for road, snow removal and maintenance work and many other applications.

Bobcat L85 FAQ

When was the Bobcat L85 manufactured?

The Bobcat L85 was first produced in 2021.

How much does the Bobcat L85 weigh?

The Bobcat L85 weighs 4.67 tons.

What are the transport dimensions of the Bobcat L85?

The Bobcat L85 has a transport length of 5.4 meters, a transport width of 1.9 meters, and a transport height of 2.4 meters.

What is the travel speed of the Bobcat L85 wheel loader?

The Bobcat L85 has a travel speed of 20 km/h.

What are the standard tyre specifications of the Bobcat L85 wheel loader?

The Bobcat L85 wheel loader is equipped with standard tyres sized 335/80 R18.

What are the maneuverability specifications of the Bobcat L85 wheel loader?

The Bobcat L85 wheel loader has an articulated-frame steering system and an outside turning radius of 3.8 meters.

What is the lifting force of the Bobcat L85 wheel loader?

The Bobcat L85 wheel loader has a lifting force of 36.9 kN.

What is the material handling capacity of the Bobcat L85 in terms of discharge height?

The Bobcat L85 has a maximum discharge height of 2.5 meters.

What are the specifications of the bucket on the Bobcat L85 wheel loader?

The Bobcat L85 wheel loader has a bucket with a capacity ranging from 0.6 to 1.2 cubic meters, a nominal capacity of 0.8 cubic meters, and a width of 1.9 meters.

How much is a Bobcat L85 Wheel loader (2021u20132025) worth?

The residual value of the Bobcat L85 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
