Avant 760i Avant Tecno Avant 760i Specifications & Technical Data (2014—2019)

The Avant Tecno Avant 760i is a wheel loader manufactured from 2014 to 2019. It has a weight of 2.1 tons and a transport length of…

The Avant Tecno Avant 760i is a wheel loader manufactured from 2014 to 2019. It has a weight of 2.1 tons and a transport length of 3.06 meters. The bucket capacity is 0.31 cubic meters with a width of 1.35 meters. The maximum discharge height is 3.1 meters. It has a travel speed of 30 km/h and a transport width of 1.08 meters. The transport height is 2.06 meters. The lifting force is 14.71 kN and the turning radius outside is 2.78 meters. It is equipped with special features such as air conditioning, quick hitch mechanism, and telescopic capabilities.

Avant 760i

Years of manufacture: 2014—2019

Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - Avant 760i Avant Tecno

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.1 t

Standard tyres: 400/50-15

Bucket width: 1.35 m

Bucket capacity: 0.31 m³

Bucket capacity min.: 0.31 m³

Steering mode: KL

Transport length: 3.06 m

Transport width: 1.08 m

Transport height: 2.06 m

Travel speed: 30 km/h

Max. discharge height: 3.1 m

Turning radius outside: 2.78 m

Lifting force: 14.71 kN

Model series: 700

Engine manuf.: Kohler

Engine type: KDI1903TCR

Engine power: 42 kW

Dimension lxwxh: 598.3x530x726 mm

Displacement: 1.86 l

Revolutions at max torque: 1500 rpm

Max. torque: 225 Nm

No. of cylinders: 3

Cylinder bore x stroke: 88x102 mm

Emission level: IIIB/T4f

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: Yes
Aircondition: Yes
Quick hitch hydr.: No
Quick hitch mech.: Yes

Avant Tecno Avant 760i FAQ

When was the Avant Tecno Avant 760i manufactured?

The Avant Tecno Avant 760i was manufactured from 2014 to 2019.

How much does the Avant Tecno Avant 760i weigh?

The Avant Tecno Avant 760i weighs 2.1 tons.

What are the transport dimensions of the Avant Tecno Avant 760i wheel loader?

The Avant Tecno Avant 760i has a transport length of 3.06 meters, a transport width of 1.08 meters, and a transport height of 2.06 meters.

What is the travel speed of the Avant Tecno Avant 760i wheel loader?

The Avant Tecno Avant 760i has a travel speed of 30 km/h.

What is the standard tyre size of the Avant Tecno Avant 760i's undercarriage?

The Avant Tecno Avant 760i has standard tyres sized 400/50-15.

What are the maneuverability specifications of the Avant Tecno Avant 760i wheel loader?

The Avant Tecno Avant 760i has an articulated-frame steering system and an outside turning radius of 2.78 meters.

What is the power rating of the Avant Tecno Avant 760i wheel loader?

The source data does not provide any power rating information for the Avant Tecno Avant 760i wheel loader.

What is the maximum discharge height of the Avant Tecno Avant 760i?

The Avant Tecno Avant 760i has a maximum discharge height of 3.1 meters.

What are the specifications of the bucket on the Avant Tecno Avant 760i wheel loader?

The Avant Tecno Avant 760i has a bucket capacity of 0.31 cubic meters, a minimum bucket capacity of 0.31 cubic meters, and a bucket width of 1.35 meters.
