AX 700 Ahlmann AX 700 Specifications & Technical Data (2010—2012)

The Ahlmann AX 700 is a wheel loader manufactured by Ahlmann from 2010 to 2012. It has a weight of 5 tons and a transport length o…

The Ahlmann AX 700 is a wheel loader manufactured by Ahlmann from 2010 to 2012. It has a weight of 5 tons and a transport length of 5.25 meters. The bucket capacity is 0.7 cubic meters, and it has a maximum discharge height of 2.86 meters. The travel speed of the wheel loader is 20 km/h. It has a transport width of 1.6 meters and a transport height of 2.47 meters. The lifting force of the machine is 41 kN. The bucket capacity is a minimum of 0.7 cubic meters. It is equipped with a quick hitch hydr. for special operations.

AX 700

Years of manufacture: 2010—2012

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AX 700 Ahlmann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5 t

Standard tyres: 12.5-18

Bucket capacity: 0.7 m³

Bucket capacity min.: 0.7 m³

Steering mode: KL

Transport length: 5.25 m

Transport width: 1.6 m

Transport height: 2.47 m

Travel speed: 20 km/h

Max. discharge height: 2.86 m

Lifting force: 41 kN

Model series: AX

Engine manuf.: John Deere

Engine type: 4024HF295

Engine power: 46 kW

Revolutions at max torque: 2000 rpm

More technical details, like: bucket width, bucket capacity max., turning radius outside, dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

Ahlmann AX 700 FAQ

When was the Ahlmann AX 700 manufactured?

The Ahlmann AX 700 was manufactured from 2010 to 2012.

How much does the Ahlmann AX 700 weigh?

The Ahlmann AX 700 weighs 5 tons.

What are the transport dimensions of the Ahlmann AX 700 wheel loader?

The Ahlmann AX 700 has a transport length of 5.25 meters, a transport width of 1.6 meters, and a transport height of 2.47 meters.

What is the travel speed of the Ahlmann AX 700?

The Ahlmann AX 700 has a travel speed of 20 km/h.

What are the undercarriage specifications of the Ahlmann AX 700 wheel loader?

The Ahlmann AX 700 wheel loader is equipped with standard tyres sized 12.5-18.

What is the steering mode of the Ahlmann AX 700?

The Ahlmann AX 700 has articulated-frame steering.

What is the lifting force rating of the Ahlmann AX 700 wheel loader?

The Ahlmann AX 700 wheel loader has a lifting force of 41 kN.

What is the maximum discharge height of the Ahlmann AX 700 wheel loader?

The Ahlmann AX 700 has a maximum discharge height of 2.86 meters.

What is the bucket capacity of the Ahlmann AX 700 wheel loader?

The bucket capacity of the Ahlmann AX 700 wheel loader is 0.7 cubic meters.
