AF 1050 Ahlmann AF 1050 Specifications & Technical Data (2010—2012)

The Ahlmann AF 1050 is a wheel loader manufactured from 2010 to 2012. It has a weight of 5.8 tons and a transport length of 6.03 m…

The Ahlmann AF 1050 is a wheel loader manufactured from 2010 to 2012. It has a weight of 5.8 tons and a transport length of 6.03 meters. The bucket capacity ranges from 1.05 to 1.7 cubic meters, with a maximum discharge height of 2.85 meters. It has a travel speed of 40 km/h and a transport width of 2.1 meters. The transport height is 2.83 meters, and it has a lifting force of 65 kN. Special equipment includes a quick hitch hydraulic mechanism.

AF 1050

Years of manufacture: 2010—2012

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - AF 1050 Ahlmann

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.8 t

Standard tyres: 14.5-20

Bucket capacity: 1.05 m³

Bucket capacity min.: 1.05 m³

Bucket capacity max.: 1.7 m³

Steering mode: AL

Transport length: 6.03 m

Transport width: 2.1 m

Transport height: 2.83 m

Travel speed: 40 km/h

Max. discharge height: 2.85 m

Lifting force: 65 kN

Model series: AF

Engine manuf.: Cummins

Engine type: B3.3

Engine power: 48 kW

Displacement: 3.3 l

Revolutions at max torque: 1600 rpm

More technical details, like: bucket width, turning radius outside, dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.

Basic model with ROPS cabin, std. shovel and teeth

Special equipment

Diesel particulate filter: No
Swing loader: No
telescopic: No
Aircondition: No
Quick hitch hydr.: Yes
Quick hitch mech.: No

Download datasheets (PDF)

AF 1050 Ahlmann Specification for Europe (DE, EN, FR)

Ahlmann AF 1050 FAQ

When was the Ahlmann AF 1050 manufactured?

The Ahlmann AF 1050 was manufactured from 2010 to 2012.

How much does the Ahlmann AF 1050 weigh?

The Ahlmann AF 1050 weighs 5.8 tons.

What are the transport dimensions of the Ahlmann AF 1050 wheel loader?

The Ahlmann AF 1050 has a transport length of 6.03 meters, a transport width of 2.1 meters, and a transport height of 2.83 meters.

What is the travel speed of the Ahlmann AF 1050 wheel loader?

The Ahlmann AF 1050 has a travel speed of 40 km/h.

What is the standard tyre size of the Ahlmann AF 1050?

The Ahlmann AF 1050 is equipped with standard tyres sized 14.5-20.

What is the steering mode of the Ahlmann AF 1050?

The Ahlmann AF 1050 has all-wheel steering.

What is the power rating of the Ahlmann AF 1050 wheel loader?

The source data does not provide power rating information for the Ahlmann AF 1050 wheel loader.

What is the maximum discharge height of the Ahlmann AF 1050?

The Ahlmann AF 1050 has a maximum discharge height of 2.85 meters.

What are the bucket capacity specifications of the Ahlmann AF 1050 wheel loader?

The Ahlmann AF 1050 wheel loader has a bucket capacity of 1.05 mu00b3, with a minimum capacity of 1.05 mu00b3 and a maximum capacity of 1.7 mu00b3.
