Technical specs - DW90-3 Wacker Neuson
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 4.748 t
- Standard tyres
- 500/60-22.5
- Net load
- 9 t
- Dump capacity
- 3.6 m³
- Dumper type
- V
- Transport length
- 4.67 m
- Transport width
- 2.486 m
- Transport height
- 3.235 m
- Travel speed
- 25 km/h
- Model series
- DW
- Engine manuf.
- Deutz
- Engine type
- TD 2.9
- Engine power
- 55.4 kW
- Displacement
- 2.925 l
- Max. torque
- 300/1600 Nm
- No. of cylinders
- 4
- Emission level
- V
More technical details, like: loading height, turning radius outside, dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Heated dump body
-
No
- All-wheel drive
-
Yes
- Track
-
No
- Aircondition
-
No
