Wacker Neuson 4001 Speed Specifications & Technical Data (2008-2021)

Technical specs - 4001 Speed Wacker Neuson

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.64 t

Standard tyres: 11.5/80-15.3

Net load: 3.5 t

Dump capacity: 1.4 m³

Dumper type: R

Transport length: 4 m

Transport width: 1.77 m

Transport height: 2.7 m

Travel speed: 25 km/h

Engine manuf.: Yanmar

Engine type: 3TNV88T

Engine power: 34.1 kW

Displacement: 2.189 l

Revolutions at max torque: 2800 rpm

No. of cylinders: 3

Emission level: III A

More technical details, like: loading height, turning radius outside, model series, dimension lxwxh, max. torque, cylinder bore x stroke, model type, driveline, rops, engine manufacturer, engine model, rated speed...

More technical details, like: loading height, turning radius outside, model series, dimension lxwxh, max. torque, cylinder bore x stroke, model type, driveline, rops, engine manufacturer, engine model, rated speed, engine output, fuel, drive, std tyre size front, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, width - front tyres, width - rear tyres, width - skip, height over skip - untipped, turning radius - outside, chassis articulation, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Buy full specs

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: No
Track: No
Aircondition: No

Download datasheets (PDF)

Wacker Neuson 4001 Speed FAQ

When was the Wacker Neuson 4001 Speed manufactured?

The Wacker Neuson 4001 Speed was manufactured from 2008 to 2021.

How much does the Wacker Neuson 4001 Speed weigh?

The Wacker Neuson 4001 Speed weighs 2.64 tons.

What are the transport dimensions of the Wacker Neuson 4001 Speed?

The Wacker Neuson 4001 Speed has a transport length of 4 meters, a transport width of 1.77 meters, and a transport height of 2.7 meters.

What is the travel speed of the Wacker Neuson 4001 Speed wheel dumper?

The Wacker Neuson 4001 Speed wheel dumper has a travel speed of 25 km/h.

What are the undercarriage tyre specifications of the Wacker Neuson 4001 Speed?

The Wacker Neuson 4001 Speed is equipped with standard tyres sized 11.5/80-15.3.

What is the material handling capacity of the Wacker Neuson 4001 Speed?

The Wacker Neuson 4001 Speed has a net load capacity of 3.5 tons and a dump capacity of 1.4 cubic meters.

How much is a Wacker Neuson 4001 Speed Wheel dumper (2008u20132021) worth?

The residual value of the Wacker Neuson 4001 Speed depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
