TA2SEH Terex TA2SEH Specifications & Technical Data (2010—2017)

Weight: 2.17t – Standard tyres: 10.0/75x15.3 10ply – Net load: 2t – Dump capacity: 1.2m³ – Dumper type: S – Transport length: 4m

TA2SEH

Years of manufacture: 2010—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - TA2SEH Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.17 t

Standard tyres: 10.0/75x15.3 10ply

Net load: 2 t

Dump capacity: 1.2 m³

Dumper type: S

Transport length: 4 m

Transport width: 1.49 m

Transport height: 2.92 m

Travel speed: 16 km/h

Loading height: 1.64 m

Turning radius outside: 3.68 m

Model series: TA

Engine manuf.: Kubota

Engine type: D1703M

Engine power: 24.5 kW

Displacement: 1.647 l

Emission level: III A

More technical details, like: dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, model type, driveline, rops, fops, engine manufacturer, engine model, emission rating, engine output, torque, fuel, drive, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, skip lip height - untipped, turning radius - outside, chassis articulation, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Terex TA2SEH FAQ

When was the Terex TA2SEH manufactured?

The Terex TA2SEH was manufactured from 2010 to 2017.

How much does the Terex TA2SEH wheel dumper weigh?

The Terex TA2SEH wheel dumper weighs 2.17 tons.

What are the transport dimensions of the Terex TA2SEH wheel dumper?

The Terex TA2SEH has a transport length of 4 meters, a transport width of 1.49 meters, and a transport height of 2.92 meters.

What is the travel speed of the Terex TA2SEH wheel dumper?

The Terex TA2SEH wheel dumper has a travel speed of 16 km/h.

What are the undercarriage tyre specifications of the Terex TA2SEH wheel dumper?

The Terex TA2SEH wheel dumper is equipped with standard tyres sized 10.0/75x15.3 10ply.

What is the outside turning radius of the Terex TA2SEH?

The Terex TA2SEH has an outside turning radius of 3.68 meters.

What is the material handling capacity of the Terex TA2SEH wheel dumper?

The Terex TA2SEH wheel dumper has a net load capacity of 2 tons and a dump capacity of 1.2 cubic meters.

How much is a Terex TA2SEH Wheel dumper (2010u20132017) worth?

The residual value of the Terex TA2SEH depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
