TA2H Terex TA2H Specifications & Technical Data (2010—2017)

Weight: 1.96t – Standard tyres: 10.0/75x15.3 10ply – Net load: 2t – Dump capacity: 1.2m³ – Dumper type: V – Transport length: 4m

Wheel Dumpers Terex TA2H

Technical specs - TA2H Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
1.96 t
Standard tyres
10.0/75x15.3 10ply
Net load
2 t
Dump capacity
1.2 m³
Dumper type
V
Transport length
4 m
Transport width
1.49 m
Transport height
2.92 m
Travel speed
16 km/h
Loading height
0.92 m
Turning radius outside
3.68 m
Model series
TA
Engine manuf.
Kubota
Engine type
D1703M
Engine power
24.5 kW
Displacement
1.647 l
Emission level
III A

More technical details, like: dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, model type, driveline, rops, fops, engine manufacturer, engine model, emission rating...

More technical details, like: dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, model type, driveline, rops, fops, engine manufacturer, engine model, emission rating, engine output, torque, drive, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, skip lip height - untipped, turning radius - outside, chassis articulation, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter
No
Heated dump body
No
All-wheel drive
Yes
Track
No
Aircondition
No

Download datasheets (PDF)

Terex TA2H FAQ

When was the Terex TA2H manufactured?

The Terex TA2H was manufactured from 2010 to 2017.

How much does the Terex TA2H wheel dumper weigh?

The Terex TA2H wheel dumper weighs 1.96 tons.

What are the transport dimensions of the Terex TA2H wheel dumper?

The Terex TA2H wheel dumper has a transport length of 4 meters, a transport width of 1.49 meters, and a transport height of 2.92 meters.

What is the travel speed of the Terex TA2H wheel dumper?

The Terex TA2H has a travel speed of 16 km/h.

What are the standard tyre specifications for the Terex TA2H wheel dumper?

The Terex TA2H wheel dumper is equipped with standard tyres sized 10.0/75x15.3 10ply.

What is the outside turning radius of the Terex TA2H wheel dumper?

The Terex TA2H has an outside turning radius of 3.68 meters.

What is the material handling capacity of the Terex TA2H wheel dumper?

The Terex TA2H wheel dumper has a net load capacity of 2 tons and a dump capacity of 1.2 cubic meters.
