TA 9 Terex TA 9 Specifications & Technical Data (2010—2014)
Technical specs - TA 9 Terex
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 4.88 t
- Standard tyres
- 500/60x22.5
- Net load
- 9 t
- Dump capacity
- 4.56 m³
- Dumper type
- V
- Transport length
- 4 m
- Transport width
- 2.5 m
- Transport height
- 3.34 m
- Travel speed
- 17.4 km/h
- Loading height
- 1.72 m
- Turning radius outside
- 6 m
- Model series
- TA
- Engine manuf.
- Perkins
- Engine type
- 1104D-44T
- Engine power
- 74.5 kW
More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Heated dump body
-
No
- All-wheel drive
-
Yes
- Track
-
No
- Aircondition
-
No
