Technical specs - TA 6 S Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.24 t

Standard tyres: 405/70-20

Net load: 6 t

Dump capacity: 3.53 m³

Dumper type: S

Transport length: 4 m

Transport width: 2.095 m

Transport height: 3.18 m

Travel speed: 26.2 km/h

Loading height: 1.671 m

Turning radius outside: 5.73 m

Model series: TA

Engine manuf.: Perkins

Engine type: 1104D-44T

Engine power: 63 kW

Displacement: 4.4 l

Revolutions at max torque: 2200 rpm

Emission level: Tier 3

More technical details, like: dimension lxwxh, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Terex TA 6 S FAQ

When was the Terex TA 6 S manufactured?

The Terex TA 6 S was manufactured from 2010 to 2014.

How much does the Terex TA 6 S wheel dumper weigh?

The Terex TA 6 S wheel dumper weighs 4.24 tons.

What are the transport dimensions of the Terex TA 6 S wheel dumper?

The Terex TA 6 S has transport dimensions of 4 meters in length, 2.1 meters in width, and 3.18 meters in height.

What is the travel speed of the Terex TA 6 S wheel dumper?

The Terex TA 6 S has a travel speed of 26.2 km/h.

What are the undercarriage specifications of the Terex TA 6 S wheel dumper?

The Terex TA 6 S wheel dumper is equipped with standard tyres sized 405/70-20.

What is the turning radius of the Terex TA 6 S wheel dumper?

The Terex TA 6 S has an outside turning radius of 5.73 meters.

What is the material handling capacity of the Terex TA 6 S wheel dumper?

The Terex TA 6 S wheel dumper has a net load capacity of 6 tons and a dump capacity of 3.53 cubic meters.
