TA 3 Terex TA 3 Specifications & Technical Data (2010—2017)

Weight: 2.28t – Standard tyres: 295/80x15.3 10ply – Net load: 3t – Dump capacity: 1.95m³ – Dumper type: V – Transport length: 4m

TA 3

Years of manufacture: 2010—2017

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - TA 3 Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.28 t

Standard tyres: 295/80x15.3 10ply

Net load: 3 t

Dump capacity: 1.95 m³

Dumper type: V

Transport length: 4 m

Transport width: 1.957 m

Transport height: 2.92 m

Travel speed: 19 km/h

Loading height: 0.208 m

Turning radius outside: 4.711 m

Model series: TA

Engine manuf.: Kubota

Engine type: V2203M

Engine power: 32.4 kW

Displacement: 2.197 l

Emission level: III A

More technical details, like: dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, model type, driveline, rops, fops, engine manufacturer, engine model, emission rating, rated speed, engine output, torque, fuel, drive, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, skip lip height - untipped, turning radius - outside, chassis articulation, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Terex TA 3 FAQ

When was the Terex TA 3 manufactured?

The Terex TA 3 was manufactured from 2010 to 2017.

How much does the Terex TA 3 wheel dumper weigh?

The Terex TA 3 wheel dumper weighs 2.28 tons.

What are the transport dimensions of the Terex TA 3 wheel dumper?

The Terex TA 3 has a transport length of 4 meters, a transport width of 1.96 meters, and a transport height of 2.92 meters.

What is the travel speed of the Terex TA 3 wheel dumper?

The Terex TA 3 has a travel speed of 19 km/h.

What are the undercarriage specifications of the Terex TA 3 wheel dumper?

The Terex TA 3 wheel dumper is equipped with standard tyres sized 295/80x15.3 10ply.

What is the turning radius of the Terex TA 3 wheel dumper?

The Terex TA 3 wheel dumper has an outside turning radius of 4.711 meters.

What is the material handling capacity of the Terex TA 3 wheel dumper?

The Terex TA 3 wheel dumper has a net load capacity of 3 tons and a dump capacity of 1.95 cubic meters.

How much is a Terex TA 3 Wheel dumper (2010u20132017) worth?

The residual value of the Terex TA 3 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Terex TA 3 overview

Skip

Features

Large heaped skip capacities. "Rental Tough" designs and fabrications to keep you working in the toughest of conditions. Thick steel skip base plate with reinforced box sections for high strength and longevity. Exceptional service access and ease of maintenance built into every machine. High ground clearance, low centre of gravity for superb stability and site accessibility. Powerful, reliable and economical Kubota engines. Power Tip (TA3 / TA3H) for forwards tip applications. Power Swivel (TA3S / TA3SH) enables effective placement of load to either side - useful for trench filling or small sites.
