TA 10 Terex TA 10 Specifications & Technical Data (2010—2014)

Weight: 5.3t – Standard tyres: 500/60x22.5 – Net load: 9t – Dump capacity: 4.56m³ – Dumper type: V – Transport length: 4m

TA 10

Years of manufacture: 2010—2014

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - TA 10 Terex

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 5.3 t

Standard tyres: 500/60x22.5

Net load: 9 t

Dump capacity: 4.56 m³

Dumper type: V

Transport length: 4 m

Transport width: 2.55 m

Transport height: 3.38 m

Travel speed: 17.4 km/h

Loading height: 1.76 m

Turning radius outside: 6.017 m

Model series: TA

Engine manuf.: Perkins

Engine type: 1104D-44T

Engine power: 75 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline, rops, engine manufacturer, engine model, emission rating, rated speed, engine output, torque, fuel, drive, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, skip lip height - untipped, turning radius - outside, chassis articulation, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Terex TA 10 FAQ

When was the Terex TA 10 manufactured?

The Terex TA 10 was manufactured from 2010 to 2014.

How much does the Terex TA 10 wheel dumper weigh?

The Terex TA 10 wheel dumper weighs 5.3 tons.

What are the transport dimensions of the Terex TA 10 wheel dumper?

The Terex TA 10 wheel dumper has a transport length of 4 meters, a transport width of 2.55 meters, and a transport height of 3.38 meters.

What is the travel speed of the Terex TA 10 wheel dumper?

The Terex TA 10 wheel dumper has a travel speed of 17.4 km/h.

What are the undercarriage tyre specifications of the Terex TA 10 wheel dumper?

The Terex TA 10 wheel dumper is equipped with standard tyres sized 500/60x22.5.

What is the turning radius of the Terex TA 10 wheel dumper?

The Terex TA 10 wheel dumper has an outside turning radius of 6.017 meters.

What is the material handling capacity of the Terex TA 10 wheel dumper?

The Terex TA 10 wheel dumper has a net load capacity of 9 tons and a dump capacity of 4.56 cubic meters.

How much is a Terex TA 10 Wheel dumper (2010u20132014) worth?

The residual value of the Terex TA 10 depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.

Terex TA 10 overview

Chassis

Features

True Operating Capacities of 9 and 10 tonnes. Large heaped skip capacities of 4560 and 5050 litres. “Rental Tough” designs and fabrications to keep you working in the toughest of conditions. 8mm thick steel skip base plate with reinforced box sections for high strength and longevity. Exceptional service access and ease of maintenance built into every machine. High ground clearance, low centre of gravity for superb stability and site accessibility. Powershuttle transmissions for ease of use and operator comfort. Powerful, reliable and economical Cummins engine.
