Technical specs - TA6S Mecalac

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.41 t

Standard tyres: 405/70-20 14PR

Net load: 6 t

Dump capacity: 3.53 m³

Dumper type: S

Transport length: 5 m

Transport width: 2.207 m

Transport height: 3.2 m

Travel speed: 26.2 km/h

Loading height: 1.258 m

Turning radius outside: 5.726 m

Model series: TA

Engine manuf.: JCB

Engine type: EcoMax

Engine power: 55 kW

Revolutions at max torque: 1250 rpm

Emission level: Tier 4 f

More technical details, like: dimension lxwxh, displacement, max. torque, no. of cylinders, cylinder bore x stroke, model type, driveline, rops, fops, telematics available, platform, fleet management, health monitoring, security, engine manufacturer, engine model, engine output, torque, fuel, drive, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, width - front tyres, width - rear tyres, height over skip - untipped, turning radius - outside, chassis articulation, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Mecalac TA6S FAQ

When was the Mecalac TA6S manufactured?

The Mecalac TA6S was manufactured from 2017 to 2020.

How much does the Mecalac TA6S wheel dumper weigh?

The Mecalac TA6S wheel dumper weighs 4.41 tons.

What are the transport dimensions of the Mecalac TA6S wheel dumper?

The Mecalac TA6S wheel dumper has a transport length of 5 meters, a transport width of 2.21 meters, and a transport height of 3.2 meters.

What is the travel speed of the Mecalac TA6S wheel dumper?

The Mecalac TA6S has a travel speed of 26.2 km/h.

What are the standard tyre specifications for the Mecalac TA6S wheel dumper's undercarriage?

The Mecalac TA6S wheel dumper is equipped with standard tyres sized 405/70-20 14PR.

What is the turning radius of the Mecalac TA6S wheel dumper?

The Mecalac TA6S has an outside turning radius of 5.726 meters.

What is the material handling capacity of the Mecalac TA6S wheel dumper?

The Mecalac TA6S wheel dumper has a net load capacity of 6 tons and a dump capacity of 3.53 cubic meters.

How much is a Mecalac TA6S Wheel dumper (2017u20132020) worth?

The residual value of the Mecalac TA6S depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
