TA3H Mecalac TA3H Specifications & Technical Data (2017—2020)
Technical specs - TA3H Mecalac
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 2.29 t
- Standard tyres
- 295/80x15.3 10ply
- Net load
- 3 t
- Dump capacity
- 1.95 m³
- Dumper type
- V
- Transport length
- 4 m
- Transport width
- 1.957 m
- Transport height
- 2.92 m
- Travel speed
- 19 km/h
- Loading height
- 0.208 m
- Turning radius outside
- 4.711 m
- Model series
- TA
- Engine manuf.
- Kubota
- Engine type
- V2203M
- Engine power
- 32.4 kW
- Displacement
- 2.197 l
- Emission level
- III A
More technical details, like: dimension lxwxh, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Heated dump body
-
No
- All-wheel drive
-
Yes
- Track
-
No
- Aircondition
-
No
