D 900 AP Ausa D 900 AP Specifications & Technical Data (2008—2014)

Weight: 4.7t – Standard tyres: 500/60-22.5 – Net load: 9t – Dump capacity: 3.7m³ – Dumper type: V – Transport length: 5m

D 900 AP

Years of manufacture: 2008—2014

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - D 900 AP Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.7 t

Standard tyres: 500/60-22.5

Net load: 9 t

Dump capacity: 3.7 m³

Dumper type: V

Transport length: 5 m

Transport width: 2.44 m

Transport height: 3.56 m

Travel speed: 40 km/h

Loading height: 1.82 m

Turning radius outside: 5.95 m

Model series: AP

Engine manuf.: Kubota

Engine type: V3800DI-T

Engine power: 78.2 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline, rops, telematics available, engine manufacturer, engine model, rated speed, engine output, fuel, drive, std tyre size front, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, width - front tyres, width - rear tyres, width - skip, skip lip height - untipped, height over skip - untipped, turning radius - outside, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Ausa D 900 AP FAQ

When was the Ausa D 900 AP manufactured?

The Ausa D 900 AP was manufactured from 2008 to 2014.

How much does the Ausa D 900 AP weigh?

The Ausa D 900 AP weighs 4.7 tons.

What are the transport dimensions of the Ausa D 900 AP wheel dumper?

The Ausa D 900 AP has transport dimensions of 5 meters in length, 2.44 meters in width, and 3.56 meters in height.

What is the travel speed of the Ausa D 900 AP wheel dumper?

The Ausa D 900 AP has a travel speed of 40 km/h.

What are the undercarriage specifications of the Ausa D 900 AP?

The Ausa D 900 AP is equipped with standard tyres sized 500/60-22.5.

What is the outside turning radius of the Ausa D 900 AP wheel dumper?

The Ausa D 900 AP has an outside turning radius of 5.95 meters.

What is the material handling capacity of the Ausa D 900 AP wheel dumper?

The Ausa D 900 AP has a net load capacity of 9 tons, a dump capacity of 3.7 cubic meters, and a loading height of 1.82 meters, featuring a front-end tipper dumper type.
