Technical specs - D 601 AHG Ausa
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 4.49 t
- Standard tyres
- 405/70-20 (16.0/70-20)
- Net load
- 6 t
- Dump capacity
- 3.154 m³
- Dumper type
- D
- Transport length
- 5.413 m
- Transport width
- 2.206 m
- Transport height
- 3.428 m
- Travel speed
- 25 km/h
- Loading height
- 1.736 m
- Turning radius outside
- 5.9 m
- Model series
- AHG
- Engine manuf.
- Deutz
- Engine type
- TD3.6 L4
- Engine power
- 55.4 kW
- Displacement
- 3.6 l
- Max. torque
- 330/1600 Nm
- No. of cylinders
- 4
- Emission level
- 3B
More technical details, like: dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Heated dump body
-
Yes
- All-wheel drive
-
Yes
- Track
-
No
- Aircondition
-
Yes
Download datasheets (PDF)
