Technical specs - D 301 AHG Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 2.3 t

Standard tyres: 11.5/80-15.3

Net load: 3 t

Dump capacity: 2.097 m³

Dumper type: D

Transport length: 4.14 m

Transport width: 1.75 m

Transport height: 2.67 m

Travel speed: 17 km/h

Loading height: 1.45 m

Turning radius outside: 4.515 m

Model series: AHG

Engine manuf.: Kubota

Engine type: V1505-E4B

Engine power: 18.5 kW

Revolutions at max torque: 2500 rpm

Max. torque: 92.6/1700 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: Yes
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Ausa D 301 AHG FAQ

When was the Ausa D 301 AHG manufactured?

The Ausa D 301 AHG was first produced in 2022.

How much does the Ausa D 301 AHG weigh?

The Ausa D 301 AHG weighs 2.3 tons.

What are the transport dimensions of the Ausa D 301 AHG wheel dumper?

The Ausa D 301 AHG has a transport length of 4.14 meters, a transport width of 1.75 meters, and a transport height of 2.67 meters.

What is the travel speed of the Ausa D 301 AHG wheel dumper?

The Ausa D 301 AHG has a travel speed of 17 km/h.

What are the undercarriage specifications of the Ausa D 301 AHG?

The Ausa D 301 AHG has standard tyres sized 11.5/80-15.3.

What is the turning radius of the Ausa D 301 AHG wheel dumper?

The Ausa D 301 AHG has an outside turning radius of 4.515 meters.

What is the material handling capacity of the Ausa D 301 AHG wheel dumper?

The Ausa D 301 AHG wheel dumper has a net load capacity of 3 tons and a dump capacity of 2.1 cubic meters.
