D 250 AHG Ausa D 250 AHG Specifications & Technical Data (2019—2021)

Weight: 2.65t – Standard tyres: 10.0/75-15.3 – Net load: 2.5t – Dump capacity: 1.56m³ – Dumper type: D – Transport length: 4.465m

Wheel Dumpers Ausa D 250 AHG
Wheel Dumpers Ausa D 250 AHG
Wheel Dumpers Ausa D 250 AHG
Wheel Dumpers Ausa D 250 AHG
Wheel Dumpers Ausa D 250 AHG
Wheel Dumpers Ausa D 250 AHG
Wheel Dumpers Ausa D 250 AHG
Wheel Dumpers Ausa D 250 AHG
Wheel Dumpers Ausa D 250 AHG
Wheel Dumpers Ausa D 250 AHG

Technical specs - D 250 AHG Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight
2.65 t
Standard tyres
10.0/75-15.3
Net load
2.5 t
Dump capacity
1.56 m³
Dumper type
D
Transport length
4.465 m
Transport width
1.77 m
Transport height
2.905 m
Travel speed
21 km/h
Loading height
1.38 m
Turning radius outside
4.3 m
Model series
AHG
Engine manuf.
Kubota
Engine type
D2403M-E3B
Engine power
36.5 kW
No. of cylinders
4
Emission level
III A

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter
No
Heated dump body
No
All-wheel drive
Yes
Track
No
Aircondition
No

Download datasheets (PDF)

Ausa D 250 AHG FAQ

When was the Ausa D 250 AHG manufactured?

The Ausa D 250 AHG was manufactured from 2019 to 2021.

How much does the Ausa D 250 AHG wheel dumper weigh?

The Ausa D 250 AHG wheel dumper weighs 2.65 tons.

What are the transport dimensions of the Ausa D 250 AHG wheel dumper?

The Ausa D 250 AHG has a transport length of 4.47 meters, a transport width of 1.77 meters, and a transport height of 2.91 meters.

What is the travel speed of the Ausa D 250 AHG wheel dumper?

The Ausa D 250 AHG wheel dumper has a travel speed of 21 km/h.

What are the standard tyre specifications of the Ausa D 250 AHG?

The Ausa D 250 AHG has standard tyres sized 10.0/75-15.3.

What is the turning radius of the Ausa D 250 AHG wheel dumper?

The Ausa D 250 AHG has an outside turning radius of 4.3 meters.

What is the material handling capacity of the Ausa D 250 AHG wheel dumper?

The Ausa D 250 AHG has a net load capacity of 2.5 tons and a dump capacity of 1.56 cubic meters.

How much is a Ausa D 250 AHG Wheel dumper (2019u20132021) worth?

The residual value of the Ausa D 250 AHG depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
