D 201 RHG Ausa D 201 RHG Specifications & Technical Data (2006—2015)

Weight: 1.9t – Standard tyres: 10l.0/75-15.3 – Net load: 2t – Dump capacity: 0.93m³ – Transport length: 4m – Transport width: 1.59m

D 201 RHG

Years of manufacture: 2006—2015

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - D 201 RHG Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.9 t

Standard tyres: 10l.0/75-15.3

Net load: 2 t

Dump capacity: 0.93 m³

Transport length: 4 m

Transport width: 1.59 m

Transport height: 1.55 m

Travel speed: 20 km/h

Loading height: 2.045 m

Turning radius outside: 4.19 m

Model series: RHG

Engine manuf.: Kubota

Engine type: V1505

Engine power: 24 kW

More technical details, like: dumper type, dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline, rops, fops, telematics available, engine manufacturer, engine model, rated speed, engine output, fuel, drive, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, width - front tyres, width - rear tyres, width - skip, skip lip height - untipped, height over skip - untipped, turning radius - outside, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Ausa D 201 RHG FAQ

When was the Ausa D 201 RHG manufactured?

The Ausa D 201 RHG was manufactured from 2006 to 2015.

How much does the Ausa D 201 RHG weigh?

The Ausa D 201 RHG weighs 1.9 tons.

What are the transport dimensions of the Ausa D 201 RHG wheel dumper?

The Ausa D 201 RHG has a transport length of 4 meters, a transport width of 1.59 meters, and a transport height of 1.55 meters.

What is the travel speed of the Ausa D 201 RHG wheel dumper?

The Ausa D 201 RHG has a travel speed of 20 km/h.

What are the undercarriage tyre specifications of the Ausa D 201 RHG?

The Ausa D 201 RHG has standard tyres sized 10l.0/75-15.3.

What is the turning radius of the Ausa D 201 RHG wheel dumper?

The Ausa D 201 RHG has an outside turning radius of 4.19 meters.

What is the material handling capacity of the Ausa D 201 RHG wheel dumper?

The Ausa D 201 RHG has a net load capacity of 2 tons, a dump capacity of 0.93 cubic meters, and a loading height of 2.05 meters.
