Ausa D 150 AHG Specifications & Technical Data (2006-2019)

Technical specs - D 150 AHG Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 1.65 t

Standard tyres: 10.0/75-15.3

Net load: 1.5 t

Dump capacity: 0.65 m³

Dumper type: D

Transport length: 3 m

Transport width: 1.45 m

Transport height: 2.6 m

Travel speed: 14 km/h

Loading height: 1.275 m

Model series: AHG

Engine manuf.: Kubota

Engine type: D1105

Engine power: 18 kW

Displacement: 1.123 l

Revolutions at max torque: 3000 rpm

No. of cylinders: 3

Emission level: III B

More technical details, like: turning radius outside, dimension lxwxh, max. torque, cylinder bore x stroke, model type, driveline, rops, fops, telematics available, engine manufacturer, engine model, rated speed...

More technical details, like: turning radius outside, dimension lxwxh, max. torque, cylinder bore x stroke, model type, driveline, rops, fops, telematics available, engine manufacturer, engine model, rated speed, engine output, fuel, drive, std tyre size front, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, width - front tyres, width - rear tyres, width - skip, skip lip height - untipped, height over skip - untipped, turning radius - outside, chassis articulation, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: No
All-wheel drive: Yes
Track: No
Aircondition: No

Download datasheets (PDF)

Ausa D 150 AHG FAQ

When was the Ausa D 150 AHG manufactured?

The Ausa D 150 AHG was manufactured from 2006 to 2019.

How much does the Ausa D 150 AHG weigh?

The Ausa D 150 AHG weighs 1.65 tons.

What are the transport dimensions of the Ausa D 150 AHG wheel dumper?

The Ausa D 150 AHG has transport dimensions of 3 meters in length, 1.45 meters in width, and 2.6 meters in height.

What is the travel speed of the Ausa D 150 AHG wheel dumper?

The Ausa D 150 AHG has a travel speed of 14 km/h.

What are the standard tyre specifications for the Ausa D 150 AHG wheel dumper?

The Ausa D 150 AHG wheel dumper is equipped with standard tyres sized 10.0/75-15.3.

What is the material handling capacity of the Ausa D 150 AHG wheel dumper?

The Ausa D 150 AHG wheel dumper has a net load capacity of 1.5 tons and a dump capacity of 0.65 cubic meters.

How much is a Ausa D 150 AHG Wheel dumper (2006u20132019) worth?

The residual value of the Ausa D 150 AHG depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
