Technical specs - D 120 AHG Ausa
Specification
Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.
- Weight
- 1.37 t
- Standard tyres
- 10.0/75-15.3
- Net load
- 1.2 t
- Dump capacity
- 0.695 m³
- Dumper type
- D
- Transport length
- 3.2 m
- Transport width
- 1.21 m
- Transport height
- 2 m
- Travel speed
- 17 km/h
- Loading height
- 1.27 m
- Turning radius outside
- 3.095 m
- Model series
- AHG
- Engine manuf.
- Kubota
- Engine type
- D1105-E4B
- Engine power
- 15.6 kW
- Revolutions at max torque
- 2400 rpm
- Max. torque
- 71.4/1600 Nm
- No. of cylinders
- 3
- Emission level
- V
More technical details, like: dimension lxwxh, displacement, cylinder bore x stroke are available in the full technical specs.
Basic model with ROPS cabin and std. trough
Special equipment
- Diesel particulate filter
-
No
- Heated dump body
-
No
- All-wheel drive
-
Yes
- Track
-
No
- Aircondition
-
No
