D 1001 AP Ausa D 1001 AP Specifications & Technical Data (2021—2022)

Weight: 4.91t – Standard tyres: 500/60-22.5 – Net load: 10t – Dump capacity: 4.24m³ – Dumper type: V – Transport length: 4.91m

D 1001 AP

Years of manufacture: 2021—2022

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - D 1001 AP Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.91 t

Standard tyres: 500/60-22.5

Net load: 10 t

Dump capacity: 4.24 m³

Dumper type: V

Transport length: 4.91 m

Transport width: 2.41 m

Transport height: 3.64 m

Travel speed: 25 km/h

Loading height: 1.77 m

Turning radius outside: 6.287 m

Model series: AP

Engine manuf.: Deutz

Engine type: TCD3.6 L4 HT

Engine power: 55.4 kW

Displacement: 3.6 l

Revolutions at max torque: 2200 rpm

Max. torque: 405/1300 Nm

No. of cylinders: 4

Emission level: V

More technical details, like: dimension lxwxh, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: Yes
Heated dump body: Yes
All-wheel drive: Yes
Track: No
Aircondition: Yes

Download datasheets (PDF)

Ausa D 1001 AP FAQ

When was the Ausa D 1001 AP manufactured?

The Ausa D 1001 AP was manufactured from 2021 to 2022.

How much does the Ausa D 1001 AP weigh?

The Ausa D 1001 AP weighs 4.91 tons.

What are the transport dimensions of the Ausa D 1001 AP wheel dumper?

The Ausa D 1001 AP has a transport length of 4.91 meters, a transport width of 2.41 meters, and a transport height of 3.64 meters.

What is the travel speed of the Ausa D 1001 AP wheel dumper?

The Ausa D 1001 AP has a travel speed of 25 km/h.

What are the undercarriage specifications of the Ausa D 1001 AP?

The Ausa D 1001 AP is equipped with standard tyres sized 500/60-22.5.

What is the turning radius of the Ausa D 1001 AP wheel dumper?

The Ausa D 1001 AP has an outside turning radius of 6.287 meters.

What is the material handling capacity of the Ausa D 1001 AP wheel dumper?

The Ausa D 1001 AP has a net load capacity of 10 tons and a dump capacity of 4.24 cubic meters.
