D 1000 AP Ausa D 1000 AP Specifications & Technical Data (2018—2021)

Weight: 4.8t – Standard tyres: 500/60-22.5 – Net load: 10t – Dump capacity: 5.225m³ – Dumper type: V – Transport length: 4.79m

D 1000 AP

Years of manufacture: 2018—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - D 1000 AP Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.8 t

Standard tyres: 500/60-22.5

Net load: 10 t

Dump capacity: 5.225 m³

Dumper type: V

Transport length: 4.79 m

Transport width: 2.425 m

Transport height: 3.5 m

Travel speed: 32 km/h

Loading height: 1.95 m

Turning radius outside: 5.95 m

Model series: AP

Engine manuf.: Deutz

Engine type: TD3.6 L4

Engine power: 55.4 kW

Displacement: 3.6 l

Max. torque: 330/1600 Nm

No. of cylinders: 4

Emission level: 3B

More technical details, like: dimension lxwxh, revolutions at max torque, cylinder bore x stroke are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: Yes
All-wheel drive: Yes
Track: No
Aircondition: Yes

Download datasheets (PDF)

Ausa D 1000 AP FAQ

When was the Ausa D 1000 AP manufactured?

The Ausa D 1000 AP was manufactured from 2018 to 2021.

How much does the Ausa D 1000 AP weigh?

The Ausa D 1000 AP weighs 4.8 tons.

What are the transport dimensions of the Ausa D 1000 AP?

The Ausa D 1000 AP has a transport length of 4.79 meters, a transport width of 2.43 meters, and a transport height of 3.5 meters.

What is the travel speed of the Ausa D 1000 AP wheel dumper?

The Ausa D 1000 AP has a travel speed of 32 km/h.

What is the standard tyre size of the Ausa D 1000 AP?

The Ausa D 1000 AP has standard tyres sized 500/60-22.5.

What is the outside turning radius of the Ausa D 1000 AP wheel dumper?

The Ausa D 1000 AP has an outside turning radius of 5.95 meters.

What is the material handling capacity of the Ausa D 1000 AP wheel dumper?

The Ausa D 1000 AP wheel dumper has a net load capacity of 10 tons and a dump capacity of 5.23 cubic meters.

How much is a Ausa D 1000 AP Wheel dumper (2018u20132021) worth?

The residual value of the Ausa D 1000 AP depends on the machine's individual parameters. Visit the LECTURA Valuation to check it.
