D 1000 AP Ausa D 1000 AP Specifications & Technical Data (2008—2021)

Weight: 4.8t – Standard tyres: 500/60-22.5 – Net load: 10t – Dump capacity: 3.8m³ – Dumper type: V – Transport length: 5m

D 1000 AP

Years of manufacture: 2008—2021

Data sheet
Buy & Rent
Valuate & Sell
Spare parts
Transport
News

Technical specs - D 1000 AP Ausa

Specification

Notice: Every data listed is verified by LECTURA Specs team experts. However, incomplete data and mistakes might occur. Contact our team with any change suggestion.

Weight: 4.8 t

Standard tyres: 500/60-22.5

Net load: 10 t

Dump capacity: 3.8 m³

Dumper type: V

Transport length: 5 m

Transport width: 2.44 m

Transport height: 4 m

Travel speed: 40 km/h

Loading height: 1.95 m

Turning radius outside: 5.95 m

Model series: AP

Engine manuf.: Kubota

Engine type: V3800DI-T

Engine power: 78.2 kW

More technical details, like: dimension lxwxh, displacement, revolutions at max torque, max. torque, no. of cylinders, cylinder bore x stroke, emission level, model type, driveline, rops, fops, telematics available, engine manufacturer, engine model, rated speed, engine output, fuel, drive, tyre size - front, tyre size - rear, service type, height over rops, width, overall length, wheelbase, ground clearance, width - front tyres, width - rear tyres, width - skip, skip lip height - untipped, height over skip - untipped, turning radius - outside, payload - heaped, payload - struck, payload - water, skip payload, travel speed - maximum, operating weight - unladen are available in the full technical specs.

Basic model with ROPS cabin and std. trough

Special equipment

Diesel particulate filter: No
Heated dump body: Yes
All-wheel drive: Yes
Track: No
Aircondition: Yes

Download datasheets (PDF)

Ausa D 1000 AP FAQ

When was the Ausa D 1000 AP manufactured?

The Ausa D 1000 AP was manufactured from 2008 to 2021.

How much does the Ausa D 1000 AP weigh?

The Ausa D 1000 AP weighs 4.8 tons.

What are the transport dimensions of the Ausa D 1000 AP wheel dumper?

The Ausa D 1000 AP has a transport length of 5 meters, a transport width of 2.44 meters, and a transport height of 4 meters.

What is the travel speed of the Ausa D 1000 AP wheel dumper?

The Ausa D 1000 AP has a travel speed of 40 km/h.

What are the undercarriage specifications of the Ausa D 1000 AP?

The Ausa D 1000 AP is equipped with standard tyres sized 500/60-22.5.

What is the turning radius of the Ausa D 1000 AP wheel dumper?

The Ausa D 1000 AP has an outside turning radius of 5.95 meters.

What is the material handling capacity of the Ausa D 1000 AP wheel dumper?

The Ausa D 1000 AP wheel dumper has a net load capacity of 10 tons and a dump capacity of 3.8 cubic meters.
